Size 70 x 10 x 1.48mm
Material Polyester
Chip NXP Ucode 9xe
EPC 128 bits TID 96 bits User N/A
Standard EPC C1G2 (ISO18000-6C)
Reading distance (fixed Reader) > 10.0m (33 ft)
Read Distance (Handheld Reader) > 7.0m(23 (ft))
Data storage>20 years
The number of erasable 100000 times
Installation method :hot pressing
RFID performance parameters
Material | Polyester |
---|---|
Dimensions | 70 x 15 x 1.5mm |
Weight | 0.3g |
Standard | EPC C1G2 (ISO18000-6C) |
Frequency | 860-960MHz (Universal) |
Chip | NXP Ucode 9xe |
EPC memory | 128 bits |
TID | 96 bits |
USER | N/A |
Reading distance (Fixed Reader) | >10.0m(33 ft) |
Read Distance (Handheld Reader) | >7.0m (23 ft) |
Data storage | 20 years |
Number of erasable | 100,000 times |
Other parameters
Working temperature | -20~85 ℃ |
---|---|
Storage temperature | -20~80 ℃ |
Operating humidity | 8%-95% RH |
Installation method | Hot pressing: 210°C,0.6-0.8MPa hot pressing for 20 seconds |
Warranty | 200 washing cycles or 3 years,which comes first |
Washing Method | Laundry,Dry cleaning |
Water Extraction Pressure | 60 bars |
Chemical resistance | Detergent,Softener,Bleach(Oxygen/Chlorine),Alkali |
Washing temperature | 90°C (194°F)/15 minutes |
Washing temperature | 180°C (356°F)/30 minutes |
Washing temperature | 185°C (365°F)/10 seconds |
Sterilization Temperature | 135℃ (275°F)/20 minutes |
Customized content | Logo, bar code/two-dimensional code, serial number, code writing, antenna design, etc. |
Application | Industrial washing management, cloth rental management, standard clothing management and washing management, police/medical/military cloth management and washing management, personnel management, etc. |
