K7030 RFID UHF anti-metal (hard) electronic tag
Speedingiot K7030 is a high-performance UHF RFID anti-metal tag. This product is widely used in indoor asset management, inspection management, and tool management. It is small in size, easy to install, and has stable and reliable product performance.
Size 70 x 30 x 5.0mm
Material PC
Chip Impinj M781
EPC 128 bits TID 96 bits User 512 bits
Standard EPC C1G2 (ISO18000-6C)
American standard reading distance (2W ERP)4.5m, metal surface
American standard reading distance (4W ERP)9.0m, metal surface
Data storage> 10 years
The number of erasable 100000 times
Installation screw, adhesive, tie
Technical Parameters
RFID performance parameters
| Material | PC |
|---|---|
| Dimensions | 70 x 30 x 5.0mm, (hole: diameter 3.3mm x 2) |
| Weight | 11.0g |
| Color | White |
| Standard | EPC C1G2 (ISO18000-6C) |
| Frequency | 902-928MHz |
| Chip | Impinj M781 |
| EPC memory | 128 bits |
| TID | 96 bits |
| USER | 512 bits |
| Waterproof grade | IP67 |
| Read Distance (2W ERP) | 4.5 m, (US Standard) 902-928MHz, metal surface |
| Read Distance (4W ERP) | 9.0 m, (US Standard) 902-928MHz, metal surface |
| Data storage | 50 years |
| Number of erasable | 100,000 times |
Other parameters
| Working temperature | -50~85 ℃ |
|---|---|
| Storage temperature | -40~85 ℃ |
| Operating humidity | 10%-95% |
| Installation method | Screw, adhesive, cable tie |
| Customized content | Logo, bar code/two-dimensional code, serial number, code writing, antenna design, etc. |
| Product Application Scenarios | Metal asset equipment management, medical equipment management, automobile management, battery car management, power management, outdoor transportation containers, iron cans and other logistics management fields. |
