S20 Warehouse Inventory Handheld Terminal

S20 is a new-generation rugged handheld computer. Built with Android 15 and Octa-Core processor, it supports optional keypad, features 5050mAh removable battery and quick charge, as well as abundant accessories. With robust data collection capability and high-powered Wi-Fi 6-ready, this mobile computer can perfectly fulfill applications in logistics, warehousing, manufacturing, retail, asset management, etc.
  • ※ Physical parameters

    Size 164×77.6×16mm
    Weight 274g

  • ※ Basic performance

    System Android 15
    Memory 3GB+32GB optional 4G+64G

  • ※ Wireless communication

    WWAN 4G WiFi 2.4G/5G dual band, Bluetooth 5.1

  • ※ Data acquisition

    Barcode scanning ; NFC reading distance 3-5cm

    • Technical Parameters

    Basic parameters

    Overall size164×77.6×16 mm
    Overall weight274 g
    Display6 inch IPS HD screen, resolution 720 * 1440
    Touch screenSupport capacitive pen multi-touch
    Battery capacity5050mAh
    Standby time About 360 hours after turn off all functions;
    Charging time Less than 4hours;
    Working hours 12hours(full charged)
    Expansion Card Slot1 sim , 1 TF
    Communication InterfaceType-c
    Indicator lampCharge indicator lamp
    KeyboardScan/power/volume button
    GPSGPS + Beidou dual navigation system
    Error range ± 5m

    Performance parameters

    CPUOcta-core 64-bit processor, 2.3GHz
    Operating SystemAndroid 15
    Memory capacityRAM: 3GB ROM: 32GB (standard)
    RAM: 4GB ROM: 64GB (optional)
    Expand memorySupport MicroSD(max 256GB expansion
    Data communication4G:TD-LTE Band38/39/40/41
    FDD-LTE Band 1 2 ,3 ,4 7, 17, , 20,
    3G:WCDMA( 850/1900/2100MHz);
    2G:GSM/GPRS/Edge
    (850/900/1800/1900MHz)
    WIFI Frequency2.4GHz/5.0GHz Dual Frequency,IEEE
    802.11 a/b/g/n/ac
    BluetoothBluetooth 5.1

    Development Environment

    SDKSoftware Development Kit
    Development LanguageJava
    Development ToolsEclipse / Android Studio

    Use of the environment

    Working temperature-20 ℃ to 50 ℃
    Storage temperature-40 ℃ to 70 ℃
    Humidity5% to 95% (non-condensing)
    Protection level IP67

    Data acquisition

    CameraFront 5 million, rear 13 million pixel camera with flash, autofocus function
    2D scan engineProfessional 2D Scan Head/Other
    Supports 2D barcode typesPDF417, MicroPDF417,Composite, RSS, TLC-39,
    Datamatrix, QR code, Micro QR code, Aztec, MaxiCode, Postal Codes, US PostNet,US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal et al.

    NFC (optional)

    Operating frequency13.56 MHz
    Protocol StandardsISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc
    Label StandardsM1 card (S50, S70), CPU card, NFC tag, etc
    Read and write distance2cm-5cm

    Annex

    Standard configuration1xPower Supply;1xLithium
    Polymer Battery; 1xType-C cable
