R7030 UHF On-metal Label
R7030 flexible anti-metal asset management label can be packaged as any kind of printed label, bar code or graphic label, and can be easily attached to curved objects, such as gas cylinders, pipes, metal containers and fixed asset equipment. Widely used in product certification, asset tracking, logistics tracking, valuables anti-counterfeiting and medical asset management and other fields.
Size 70x30x1.0mm
Material can be printed white PET material
Chip Alien Higgs 9
User 688 bits; EPC 96(up to 496) bits; TID 48 bits
Standard EPC C1G2 (ISO18000-6C)
Read Range(Fixed Reader) FCC: 10.5 m
10 years of data storage
The number of erasable 100000 times
Technical Parameters
Electrical Performance
| Material | Printable white PET material |
|---|---|
| Dimensions | 70x30x1.0mm |
| Standard | EPC C1G2 (ISO18000-6C) |
| Frequency | 902-928MHz |
| Chip | Alien Higgs 9 |
| EPC memory | 96(up to 496) bits |
| TID | 48 bits |
| User Area Memory | 688 bits |
| Read Range(Fixed Reader) | FCC: 10.5 m, on metal; 5.5 m, on plastic borad |
| Data storage | 10 years |
| Number of erasable | 100000 times |
Other parameters
| Working temperature | -20 ℃ ~ 85 ℃ |
|---|---|
| Storage temperature | -30 ℃ ~ 100 ℃ |
| Storage humidity | 10%-95% |
| Application surface | metal surface |
| Installation method | Adhesive paste |
| Support Printer | SATO CL4NX, Zebra ZT410 Silverline, Postek TX3r, etc. |
| Customized content | Logo, bar code/two-dimensional code, serial number, code writing, antenna design, etc. |
| Packing specification | Roll inner diameter: 76.2mm (3 inches) ,500 pieces/roll |
| Product Application Scenarios | Metal container tracking, equipment management, warehouse shelves, auto parts tracking, IT asset management, etc. |
