PD16 RFID asset tracking and RFID logistics tracking Tag
Speedingiot PD16 is UHF RFID tag, which can be used for rfid asset tracking and rfid logistics tracking solution. PD16 RFID asset tracking tag operates on the US frequency 902-928MHZ and EUR frequency 865-868MHZ compliant with EPC Class1 Gen2, ISO18000-6C with 2.6 meters read range using fixed reader. it is shape in size dia 16mm,thickness in 3.0mm ,with 2 holes in diameter 2mm ,chip in Alien H3 EPC number can up to 480 bits ,user 512 bits ,TID 64bits ,which the data retention can up to 50 years ,write cycles in 100000 times.
Size Dia16 x 3.0 mm (Hole: D 2mm*2)
Material FR4(PCB)
Chip Alien Higgs-3
EPC 96bits (Up to 480bits) , USER 512bits, TID64bits
Standard EPC C1G2 (ISO18000-6C)
Reading distance (4W ERP)2.6 m, metal surface
Data storage> 10 years
The number of erasable 100000 times
Installation method Industrial grade viscose
Technical Parameters
RFID performance parameters
| Material | PCB |
|---|---|
| Dimensions | Dia 16 x 3.0 mm |
| Weight | 1.3g |
| Color | Black, customizable |
| Standard | EPC C1G2 (ISO18000-6C) |
| Frequency | (US Standard) 902-928MHz, (European Standard) 865-868MHz, (GB) 920-925MHz |
| Chip | Alien Higgs-3 |
| EPC memory | 96 bits |
| TID | 64 bits |
| USER | 512 bits |
| Waterproof grade | IP68 |
| Reading distance (4W fixed reader) | 2.6 m, metal surface (US) 2.4 m, metal surface (EU) |
| Reading distance (2W handheld reader) | 1.6 m, metal surface (US) 1.5 m, metal surface (EU) |
| Data storage | 50 years |
| Number of erasable | 100,000 times |
Other parameters
| Working temperature | -20~150 ℃ |
|---|---|
| Storage temperature | -20~100 ℃ |
| Operating humidity | 10%-95% |
| Installation method | Adhesive |
| Customized content | Logo, bar code/two-dimensional code, serial number, code writing, antenna design, etc. |
| Application | Small tool management, precision measurement tool management, embedded management of items, etc. |
