X6 long-distance RFID handheld terminal
X6 is a UHF handheld terminal developed in Speedingiot based on Android system, MTK6772 platform eight nuclear CPU,4G communication, 5.5-inch HD large screen, resolution as high as 1440*720, visible under strong light; 2.4G & 5G dual-frequency Wi-Fi can realize one-dimensional/two-dimensional barcode scanning, UHF RFID reading and writing, NFC, photographing, fingerprint identification multifunctional equipment, and large-capacity battery 9000 mA, ensure the efficiency and stability of enterprise user mobile data collection. The structural design has strong durability and is widely used in many industries, such as supermarket retail, logistics and warehousing, asset management, electric power, government & public utilities, banks, order fest, admission ticket inspection and so on.
Size 166 × 79 × 31mm (excluding shield and handle)
Screen 5.5 inch IPS HD screen, resolution 720*1440
System Android 10 (high-end eight-core CPU)
Memory 4G + 64G
WWAN 4G/ WIFI Dual Band BT4.1
Barcode recognition RFID UHF and NFC high frequency reading
Chip Impinj E series module, read distance> 25 meters, 33dBm, adjustable
Large battery when the battery is 9000 mA; durable
Technical Parameters
Basic parameters
| Overall size | 166 × 79 × 31mm (excluding shield and handle) |
|---|---|
| Weight of whole machine | 650 g |
| Display | 5.5 inch IPS HD screen, resolution 720*1440 |
| Touch screen | Corning Gorilla Glass, multi-touch, support gloves or wet hand operation |
| Battery capacity | Rechargeable lithium polymer battery 9000 mAh Standby time> 360 hours Working hours> 14 hours (depending on usage and network environment) Charge time <6 hours (using standard power adapter and cable) |
| Expansion Card Slot | 1 sim card slot (MUP-C785), 1 TF card slot 1 PSAM card slot (MUP-C785, ISO7816 standard PSAM card of NANO) |
| Communication Interface | USB 2.0 Type-C,OTG |
| Notifications | Sound, LED indicator, vibrator |
| Sensor | Light sensor, distance sensor |
| Audio | 1 microphone; 1 speaker; earpiece |
| Keyboard | 2 scan keys, 1 power key, 1 volume key, Front 4 Custom Entity Buttons |
Performance parameters
| CPU | Cortex-A53 64-bit octa-core 2.0 GHz |
|---|---|
| Operating System | Android 10 |
| Memory | 4 GB + 64 GB |
| Expand memory | Expandable MicroSD (TF) card to 256 GB |
| Wireless Communication WWAN | 4G:TD-LTE Band38/39/40/41 FDD-LTE Band B1/ B2/B3/B4/B7/B17/B20 3G:WCDMA( 850/1900/2100MHz); 2G:GSM/GPRS/Edge |
| WIFI Frequency | Support IEEE802.11 a/B/g/n/ac protocol (2.4G/5.8G dual band) |
| Positioning System | GPS and Beidou dual navigation system, error range ± 5m |
| Bluetooth | Bluetooth 4.1 |
Development Environment
| SDK | Software Development Kit |
|---|---|
| Development Language | Java |
| Development Tools | Eclipse / Android Studio |
Data acquisition
| Camera | Front 5 million pixel camera Rear 13 million pixel camera Support auto focus, flash |
|---|
RFID UHF (optional)
| Operating frequency | China 920-925 MHz USA 902-928 MHz Europe 865-868 MHz |
|---|---|
| RFID Engine | Development based on Impinj E710 chip |
| Protocol Standards | EPC C1 GEN2 / ISO18000-6C |
| Antenna parameters | Circularly polarized antenna (5.5dBi) |
| Power | 2W(33dBm, support 5dBm ~ 33dBm adjustment) |
| card reading distance | 1-30m (Alian H3 anti-metal tag, size 130 x 42mm) |
| Group Read Rate | Up to 800 tags/s (circular polarization) |
| Test Description | The actual use of card reading distance and group reading rate is related to the environment and label. |
NFC (optional)
| Operating frequency | 13.56 MHz |
|---|---|
| Protocol Standards | ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc |
| Label Standards | M1 card (S50, S70), CPU card, NFC tag, etc |
| Read and write distance | 2-5cm |
| Optional high frequency | Long-distance high-frequency reading distance above 10cm |
Barcode scanning (optional)
| Scan Engine | Zebra 4710/Honeywell HS7/N6703/New World N1/Other |
|---|---|
| Type of support | UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: USPostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX), etc |
Use of the environment
| Working temperature | -20 ℃ to 50 ℃ |
|---|---|
| Storage temperature | -40 ℃ to 70 ℃ |
| Ambient humidity | 5% to 95% (non-condensing) |
| Protection level | Host IP65 |
Annex
| Standard accessories | Battery, adapter, data cable, lanyard |
|---|---|
| Optional Accessories | Charging seat charging (optional with network port) |
