CT002 Rod Type Low Frequency Reader

CT002 is a hand-held stick-type low-frequency tag reader. It adopts wireless reading mode and supports FDX-B conforming to ISO 11784/11785 international standard. FDX-A,HDX format electronic tags, the product adopts 1.5-inch color OLED display screen and Bluetooth wireless communication function, which is convenient for real-time communication with mobile phones and all-round control of the device through mobile phone APP. Users can also communicate data with the computer via a USB data cable. The product has stable performance, simple operation, suitable for animal husbandry, urban community security, public security inspection use.
  • ※ physical parameters

    Size 650 x 65 x 48 mm
    Screen 1.5 inches, pixel 128*128

  • ※ basic performance

    Standard ISO11784/5 and ISO14223; frequency 134.2kHz
    System support Android, IOS demo APP

  • ※ wireless communication

    USB and Bluetooth data transfer

  • ※ data acquisition

    HDX 27mm ear tag = max 50 cm
    FDX-B 27mm ear tag = max 3cm

  • CT002 handheld animal ear tag reader

    Technical Parameters

    Basic parameters

    Dimensions650 x 65 x 48 mm
    Weight485g
    Communication modeUSB and Bluetooth
    LanguageEnglish, French, Spanish, Italian, Portuguese, German, Polish
    DisplayColor screen 1.5 inches, pixel 128*128
    Signal indicationBuzzer
    Power supplyBuilt-in 7.4V @ 2600mA lithium battery
    Battery lifeAfter the battery is fully used for 16 hours
    Storage capacityMaximum 100000 messages (timestamp code).
    LengthDefault 65cm (more than 1 m can be adjusted according to customer requirements)

    RF Performance

    Frequency134.2kHz
    Read CriteriaISO11784/5 and ISO14223
    FDX-A FDX-B HDX and EM4102
    Data storageMore than 1 million
    Full-standard reading distanceHDX 27mm ear tag = max 50 cm
    FDX-B 27mm ear tag = max 3cm
    FDX-B 2x 12mm glass tube = max 19cm
    FDX-A 2x 12mm glass tube = 8cm
    Read Time<1s
    Protection/ResistanceIP65 waterproof/free fall ground 1 m high (IP67 can be customized)
    CertificationCE, FCC, RoHS

    Development Environment

    Operating SystemAndroid, IOS
    SDKProvide relevant SDK development package

    Use of the environment

    Working temperature-25 ℃ to 50 ℃
    Storage temperature-20 ℃ to 70 ℃
    Ambient humidity5% to 95% (non-condensing)

    Annex

    Standard accessoriesPower adapter, warranty card, etc.
    OptionalOptional phone holder
