Wireless manhole cover sensor

The wireless manhole cover sensor developed by Swift Wireless is installed at the bottom of the manhole cover, which can realize manhole cover opening monitoring, overflow monitoring, data uploading, abnormal state alarm and other functions. A single sensor can work independently and support networking communication with the company's gateway (choose the communication method according to customer needs). The transmission distance between networking and terminal information collector, wireless Internet of Things gateway and wireless signal repeater is 40~50m, with battery. Ultra-high protection level, suitable for all kinds of environment.
  • ※ basic performance

    Acceleration sensor range -16g ~ 16g, accuracy 0.1g (adjustable)
    Response time ≤ 1S displacement trigger real-time communication,<16S (network sleep to start transmission)

  • ※ wireless communication

    S485(Modbus RTU protocol)/Bluetooth;

  • Technical Parameters

    Basic performance

    Product ModelXHS-JN02
    Product size98x76x32MM
    Communication modeNB communication/ad hoc network communication
    Product materialEngineering PC
    Dip angle monitoring range-90 ° ~ 90 °
    Acceleration sensing accuracy0.1g (adjustable)
    Acceleration sensor range-16g ~ 16g
    sensor real-timeDisplacement trigger real-time communication
    network real-time<16S (network sleep to start transmission)
    Overflow monitoring (optional)0/1 switching value
    Single-node communication distanceVisual range of 40M (installation distance depends on the actual application scenario)

    Use of the environment

    Protection levelIP68
    Working temperature-40 to 85°C
    Relative humidity≤99.9%RH
