BATTERYLESS ORIENTATION/TILT SENSOR

KINEO-RM is an EPC Class-1 Generation-2 (C1G2) RFID tag based on Farsens'batteryless sensor technology. Built in a compact PCB format, the tag includes an accelerometer. These RFID sensor tags are compatible with commercial UHF RFID readers (EPC C1G2). With a 2W ERP setup the battery-less orientation sensor can communicate to over 5 meters - 16 feet. The KINEO-RM can be customized with different antenna design and sizes, depending on the specific application. It can be encapsulated in an IP67 or IP68 casing for usage in harsh environments. It may also be possible to customize the specifications of the sensor upon request.
  • ※ physical parameters

    Size: 137.25 X 17.05 X 10 mm

  • ※ RFID performance

    Standard EPC C1G2 (ISO18000-6C)

  • ※ Memory

    160-bit EPC Bank, 96-bit TID Bank, 1008-bit User

  • ※ Characters

    3-axis accelerometer (X,Y,Z)

  • 传感器应用横幅图

    Technical Parameters

    RFID

    Model No.EVAL01-KINEO-RM
    StandardEPC C1G2 (ISO18000-6C)
    Memory160-bit EPC Bank, 96-bit TID Bank, 1008-bit User
    Operation range full passeive 5 m
    Operation range BAP15 m
    Operation range EBAP20 m

    Operation Conditions

    Operating temperature range-40~ 85 ℃
    Acceleration range±4g
    Acceleration accuracy±40 mg
    Acceleration resolution2mg
