C1005 Ceramic Anti-metal Tag

Speedingiot C1005 is a long-distance electronic tag designed for precious metal objects. It is a UHF RFID ceramic tag developed based on R6P chip. The size is 10 x 5.0 x 3.0mm, which meets the EPC Class 1 Gen 2 standard. When it is fixed on the surface of a metal asset, the reading distance can reach more than 6 meters. Ambient temperature -40~200 ℃, can be embedded in the mold use. Widely used in mold management, high-value IT assets, embedded tools, asset management, etc.
  • ※ physical parameters

    Size 10 x 5 x 3 mm
    Material Ceramic

  • ※ chip specifications

    Chip Impinj R6-P
    EPC 128 bits TID 96 bits User 32 bits

  • ※ RFID performance

    Standard EPC C1G2 (ISO18000-6C)
    Reading distance (4W ERP)3.0 m, metal surface
    Reading distance (4W ERP)0.5 m, non-metallic surface

  • ※ data acquisition

    Data storage> 10 years
    The number of erasable 100000 times
    Installation method Industrial grade viscose/high quality epoxy glue

  • Technical Parameters

    RFID performance parameters

    MaterialCeramics
    Dimensions10 x 5 x 3.0mm
    Weight0.85g
    ColorSilver
    StandardEPC C1G2 (ISO18000-6C)
    Frequency(US Standard) 902-928MHz,(European Standard) 865-868MHz,(GB) 920-925MHz
    ChipImpinj R6P
    EPC memory128 bits
    TID96 bits
    USER32 bits
    Waterproof gradeIP68
    Read Distance3.0 m, metal surface
    Read Distance0.5 m, non-metallic surface
    Data storage50 years
    Number of erasable100,000 times

    Other parameters

    Working temperature-30~85 ℃
    Storage temperature-30~200 ℃
    Operating humidity10%-95%
    Installation methodIndustrial grade viscose/high quality epoxy adhesive
    Customized contentLogo, bar code/two-dimensional code, serial number, code writing, antenna design, etc.
    Product Application ScenariosInspection of electrical equipment, inspection of towers and poles, inspection of elevators, management of pressure vessels, cylinders and cylinders, management of automobile parts, management of medical devices, management of guns, etc.
