EPC C1G2 BATTERYLESS BISTABLE RELAY
These RFID sensor tags are compatible with commercial UHF RFID readers (EPC C1G2). With a 2W ERP setup the battery-less resistance meter can communicate to over 5 meters - 16 feet.
The TITAN-R can be customized with different antenna design and sizes, depending on the specific application. It can be encapsulated in an IP67 or IP68 casing for usage in harsh environments. It may also be possible to customize the specifications of the relay upon request.
Size: 137.25 X 17.05 X 10 mm
Standard EPC C1G2 (ISO18000-6C)
160-bit EPC Bank, 96-bit TID Bank, 1008-bit User
Bistatic relay to open/close/switch electrical
circuits
Technical Parameters
RFID
| Model No. | EVAL01-TITAN-R-V01 |
|---|---|
| Standard | EPC C1G2 (ISO18000-6C) |
| Memory | 160-bit EPC Bank, 96-bit TID Bank, 1008-bit User |
| Operation range full passeive | 5 m |
| Operation range BAP | 15 m |
| Operation range EBAP | 20 m |
Operation Conditions
| Operating temperature range | -40~ 85 ℃ |
|---|---|
| Contact type | 2 Form C |
| Contact material | Silver alloy with gold alloy overlay |
| Contact resistance | 75 mΩ |
| Switching voltage (AC) | 250 V |
| Switching voltage (DC) | 220 V |
| Switching current | 2 A |
| Switching power | 60 W |
| Switching apparent power | 120 VA |
| Durability with load | 1.000.000 ops |
| Durability with no load | 10.000.000 ops |
