PA3003 Industrial Code Body Identification
Swift wireless PA5005 industrial carrier body logo is a kind of industrial label suitable for harsh conditions. The shell is made of PPS resin material, which has good performance in corrosion resistance and high temperature wear resistance. At the same time, the label has a variety of chips and frequency options to meet the different needs of the site.
Dimension Φ 30mm X 3mm Middle hole φ5mm
Material PA
ICODE SLIX2
EEPROM 1024 Bit USER DATA 896 bit
Standard ISO15693
Read and write distance 2~10cm
The number of erasable 100000 times
Installation method Adhesive fixing/rivet fixing/screw fixing
Technical Parameters
Technical parameters
| Dimensions | Φ 30mm X 3mm middle hole position Φ 5mm |
|---|---|
| Material | PA |
| Packaging process | injection molding |
| Color | Black |
| Weight | 3 g |
| Chip Memory | EEPROM 1024 Bit USER DATA 896 bit |
| Read and write function | Can read and write |
| Operating frequency | 13.56MHZ ± 0.3MHZ |
| Working Agreement | ISO 15693 |
| Data retention time | > 10 years |
| Data rewriting times | > 100,000 times |
Other parameters
| Working temperature | -20 ℃ ~ 65 ℃ (no icing) |
|---|---|
| Storage temperature | -30°C to 75°C |
| Operating humidity | 10%-95% |
| Power supply mode | Passive |
| Installation method | Adhesive fixing/rivet fixing/screw fixing |
| Customized content | Serial number, code writing, antenna design, etc. |
| Temperature resistance | Long-term: 150 ℃ for 60 minutes; Short-term: 180 ℃ for 10 minutes; |
