ROCKY100 EVALUATION BOARD
SPIDER-R is an EPC Class-1 Generation-2 (C1G2) RFID tag based on Farsens’ batteryless sensor technology. Built in a compact PCB format, the tag includes a ROCKY100 IC. These RFID tags are compatible with commercial
UHF RFID readers (EPC C1G2). With a 2W ERP setup the battery-less resistance meter can communicate to over 5 meters - 16 feet.
Size: 137.20 X 21.50 X 10 mm
Standard EPC C1G2 (ISO18000-6C)
160-bit EPC Bank, 96-bit TID Bank, 1008-bit User
All pinning available at connector
Technical Parameters
RFID
| Model No. | EVAL01-SPIDER-R-V03 |
|---|---|
| Standard | EPC C1G2 (ISO18000-6C) |
| Memory | 160-bit EPC Bank, 96-bit TID Bank, 1008-bit User |
| Operation range full passeive | 5 m |
| Operation range BAP | 15 m |
| Operation range EBAP | 20 m |
Operation Conditions
| Operating temperature range | -40~ 85 ℃ |
|---|
