K7421 long-range anti-metal tag

Fast wireless K7421 is a long-distance industrial level anti-metal electronic tag, based on M730 chip development of UHF RFID special tags. The size is 74x 21x 8.4mm, which meets the EPC Class 1 Gen 2 standard. When it is fixed on the surface of a metal asset, the reading distance can reach more than 15 meters. Protection up to IP68, waterproof UV acid and alkali resistant, can be used outdoors for a long time. Widely used in heavy machinery and equipment management, outdoor vehicles, containers, forklift management, pallet cargo management, field asset management.
  • ※ physical parameters

    Dimensions 74 x 21 x 8.4mm
    Material engineering plastics, surface material high quality PET

  • ※ chip specifications

    Chip Impinj M730
    EPC 128 bits TID 96 bits User 0 bits

  • ※ RFID performance

    Standard EPC C1G2 (ISO18000-6C)
    Reading distance (2W ERP)15.0 m, metal surface
    Reading distance (2W ERP)6.0 m, non-metallic surface

  • ※ data acquisition

    Data storage> 10 years
    The number of erasable 100000 times
    Installation method Industrial grade adhesive/rivet hole

  • Technical Parameters

    RFID performance parameters

    MaterialLabel Material Engineering Plastic, Surface Material high quality PET
    Dimensions74 x 21 x 8.4mm
    Weight8.8g
    ColorGray, black
    StandardEPC C1G2 (ISO18000-6C)
    Frequency(US Standard) 902-928MHz,(European Standard) 865-868MHz,(China) 920-925MHz
    ChipImpinj M730
    EPC memory128 bits
    TID96 bits
    USER0 bits
    Waterproof gradeIP68
    Read Distance (2W ERP)15 m, metal surface
    6.0 m, non-metallic surface
    Data storage50 years
    Number of erasable100,000 times

    Other parameters

    Working temperature-30~85 ℃
    Storage temperature-40~150 ℃
    Operating humidity10%-95%
    Installation methodIndustrial grade adhesive/rivet hole
    Customized contentLogo, bar code/two-dimensional code, serial number, code writing, antenna design, etc.
    Product Application ScenariosMetal asset equipment management, medical equipment management, automobile management, battery car management, power management, outdoor transportation containers, iron cans and other logistics management fields.
