D01 micro UHF desktop reader

D01 is a delicate and compact UHF RFID desktop all-in-one machine. Based on the design of high-performance ultra-high frequency chip, it fully supports electronic tags conforming to EPC Global C1 Gen2/ISO 18000-6C/6B protocol, and can support GB/T29768 and GJB7377.1 protocols at the same time. Combined with a proprietary efficient collision processing algorithm, it realizes fast reading and writing processing of electronic tags. HID USB interface without driver installation, easy to install and deploy. It can be widely used in various radio frequency identification systems such as personal identification, conference check-in system, access control system, anti-counterfeiting system and production process control.
  • ※ Physical parameters

    Size 150*102*16mm
    Weight 255g

  • ※ Basic performance

    Domestic chip
    System support Windows, Linux

  • ※ Communication interface

    Support USB drive-free communication
    Interface Type-C Interface

  • ※ RFID performance

    Read and write UHF tags support readable and writable
    Power maximum power 27dBm, step adjustable

  • Technical Parameters

    Basic parameters

    Overall size150*102*16mm (length * width * height)
    Weight of whole machine255g
    MaterialAluminum profile tempered glass panel
    Communication InterfaceUSB

    UHF performance parameters

    Operating frequencyChina 920-925 MHz; USA 902-928 MHz; Europe 865-868 MHz(ETSI EN 302 208)
    Protocol StandardsEPC C1 GEN2 / ISO18000-6C/ GB/T29768, GJB7377.1
    Antenna parametersBuilt-in near-field antenna
    PowerOutput power software adjustable, step interval ± 1dB, maximum 27dBm
    Group Read RateMulti-label recognition performance> 50 sheets
    Counting ModeReal-time inventory, cache inventory
    Indicator lightRed, green and blue three-color indicator light

    Working environment

    Working temperature-20 ℃ to 70 ℃
    Storage temperature-40 ℃ to 85 ℃
    Working humidity0 ℃ to 90 ℃
    Storage humidity0 ℃ to 65 ℃

    Annex

    Standard accessoriesUSB cable * 1
