K10530 High Protecting On-metal Tag

K10530 is a high-performance UHF RFID anti-metal tag. This product is widely used in indoor asset management, inspection management, and tool management. It is small in size, easy to install, and has stable and reliable product performance. This hard-shell industrial label has the characteristics of anti-drop, impact resistance, wear resistance, long identification distance, excellent metal resistance, and good encryption; it is especially suitable for metal asset equipment management, medical device management, automobile management, battery car management, Logistics management fields such as power management, outdoor transportation containers, iron cans, etc.
  • ※ physical parameters

    Size 105 x 30 x 7.5mm
    Material ABS PC

  • ※ chip specifications

    Chip NXP UCODE 8
    EPC 128 bits TID 96 bits User 0 bits

  • ※ RFID performance

    Standard EPC C1G2 (ISO18000-6C)
    American standard reading distance (4W ERP)19m, metal surface

  • ※ data acquisition

    Data storage> 10 years
    The number of erasable 100000 times

  • RFID asset tracking system

    Technical Parameters

    RFID performance parameters

    MaterialABS PC
    Dimensions105 x 30 x 7.5mm, (hole: diameter 5.2mm x 2)
    Weight26g
    ColorWhite
    StandardEPC C1G2 (ISO18000-6C)
    Frequency(US Standard) 902-928MHz,(European Standard) 865-868MHz
    ChipNXP UCODE 8
    EPC memory128 bits
    TID96 bits
    USER0 bits
    Waterproof gradeIP68
    Read Distance (2W ERP)7.0 m, (US Standard) 902-928MHz, metal surface
    7.5 m, (European standard) 865-868MHz, metal surface
    Read Distance (4W ERP)19.0 m, (US Standard) 902-928MHz, metal surface
    20.0 m, (European standard) 865-868MHz, metal surface
    Data storage50 years
    Number of erasable100,000 times

    Other parameters

    Working temperature-45~85 ℃
    Storage temperature-25~85 ℃
    Operating humidity10%-95%
    Installation methodScrew, adhesive, cable tie
    Customized contentLogo, bar code/two-dimensional code, serial number, code writing, antenna design, etc.
    Product Application ScenariosMetal asset equipment management, medical equipment management, automobile management, battery car management, power management, outdoor transportation containers, iron cans and other logistics management fields.
