K6923 Long-range anti-metal tag
K6923 is a hard shell outdoor label with excellent weather resistance and impact resistance developed by Speedingiot. The label has a built-in NXP UCODE 8 chip and the shell is packaged with ABS PC material. It can not only resist the impact of strong impact force, but also has good anti-metal properties. This anti-metal electronic label with hard shell is widely used in automobile management, battery car management, asset management, power management and outdoor transportation containers, iron cans and other logistics management areas.
Size 69 x 23 x 7.0mm
Material ABS PC
Chip NXP U CODE 8
EPC 128 bits TID 96 bits User 0 bits
Standard EPC C1G2 (ISO18000-6C)
American standard reading distance (2W ERP)5.5m, metal surface
American standard reading distance (4W ERP)11.0m, metal surface
Data storage> 10 years
The number of erasable 100000 times
Installation screw, adhesive, tie
Technical Parameters
RFID performance parameters
| Material | ABS PC |
|---|---|
| Dimensions | 69 x 23 x 7.0mm, (hole: diameter 5.2mm x 2) |
| Weight | 10.8g |
| Color | White |
| Standard | EPC C1G2 (ISO18000-6C) |
| Frequency | (US Standard) 902-928MHz, (European Standard) 865-868MHz |
| Chip | NXP U CODE 8 |
| EPC memory | 128 bits |
| TID | 96 bits |
| User Area Memory | 0 bits |
| Waterproof grade | IP68 |
| Read Distance (2W ERP) | 5.5 m, (US Standard) 902-928MHz, metal surface 5.0 m, (European standard) 865-868MHz, metal surface |
| Read Distance (4W ERP) | 11.0 m, (US Standard) 902-928MHz, metal surface 10.0 m, (European standard) 865-868MHz, metal surface |
| Data storage | 50 years |
| Number of erasable | 100,000 times |
Other parameters
| Working temperature | -40~85 ℃ |
|---|---|
| Storage temperature | -25~85 ℃ |
| Operating humidity | 10%-95% |
| Installation method | Screw, adhesive, cable tie |
| Customized content | Logo, bar code/two-dimensional code, serial number, code writing, antenna design, etc. |
| Product Application Scenarios | Car management, battery car management, asset management, power management, outdoor transport containers, cans and other logistics management areas |
