PM7020 PCB anti-metal tag

PM7020 is a medium-sized anti-metal radio frequency electronic tag, based on the Alien H9 chip developed UHF RFID special tag. Size 70 x 20 x 4mm, EPC Class 1 Gen 2 and RoHS compliant, IP68 protection. The shell is enclosed by high quality epoxy resin, which is strong and durable. Applicable to tools, molds, valuable electronic equipment and other asset management. Use high quality epoxy glue to fix on the surface of metal assets, reading distance of up to 14 meters. The label is light, easy to install, waterproof, high security, indoor and outdoor universal, is a high-quality choice for asset management.
  • ※ physical parameters

    Size 70 x 20 x 4.0mm
    Material FR4(PCB)

  • ※ chip specifications

    Chip Alien H9
    EPC 96 bits TID 96 bits User 688 bits

  • ※ RFID performance

    Standard EPC C1G2 (ISO18000-6C)
    Reading distance (4W ERP)14.0 m, metal surface

  • ※ data acquisition

    Data storage> 10 years
    The number of erasable 100000 times
    Installation method Industrial grade viscose/high quality epoxy glue

  • Technical Parameters

    RFID performance parameters

    MaterialFR4 surface material: industrial grade epoxy resin
    Dimensions70 x 20 x 4.0mm
    Weight2.0g
    ColorWhite, customizable
    StandardEPC C1G2 (ISO18000-6C)
    Frequency902-928MHz
    ChipAlien H9
    EPC memory96 bits
    TID96 bits
    USER688 bits
    Waterproof gradeIP68
    Reading distance (4W fixed machine)14.0 m, metal surface
    Data storage50 years
    Number of erasable100,000 times

    Other parameters

    Working temperature-80~85 ℃
    Storage temperature-80~185 ℃
    Operating humidity10%-95%
    Installation methodIndustrial grade viscose/high quality epoxy adhesive
    Customized contentLogo, bar code/two-dimensional code, serial number, code writing, antenna design, etc.
    Product Application ScenariosInspection of electrical equipment, inspection of towers and poles, inspection of elevators, management of pressure vessels, cylinders and cylinders, management of automobile parts, management of medical devices, management of guns, etc.
