K13042 hard UHF anti-metal electronic tag
K13042 is a fast wireless high-performance UHF RFID anti-metal tag, this product is widely used in indoor asset management, inspection management, and tool management, small size, easy installation, product performance is stable and reliable.
Size 130*42*10.5mm
Material PC
Chip Alien Higgs-3
EPC 96 bits TID 64 bits User 688 bits
Standard EPC C1G2 (ISO18000-6C)
US Standard Reading Distance (2W ERP)22m, Metal Surface
European standard reading distance (2W ERP)22m, metal surface
Data storage> 10 years
The number of erasable 100000 times
Installation method Industrial grade viscose/high quality epoxy glue
Technical Parameters
Technical parameters
| Dimensions | 130*42*10.5mm |
|---|---|
| Materials | PC |
| Color | Black (optional red, blue, green, white) |
| RFID Protocol | EPC Class1 Gen2, ISO18000-6C |
| Frequency | (US Standard) 902-928MHz, (European Standard) 865-868MHz |
| Storage | EPC 96bits (expandable to 480bits), user area 688 bits,TID64 bits |
| Waterproof grade | IP68 |
| Read Pitch (4 Watt Fixed Machine) | 30 m, (US Standard) 902-928MHz, metal surface 16 m, (European standard) 865-868MHz, metal surface |
| Read Pitch:(2 Watt Handset) | 22 m, (US Standard) 902-928MHz, metal surface 11 m, (European standard) 865-868MHz, metal surface |
| Application surface | metal surface |
| Data saving | 50 years |
| Number of writes | 100,000 times |
Other parameters
| Working temperature | -40~100 ℃ |
|---|---|
| Storage temperature | -40~80 ℃ |
| Working humidity | 10% to 90% |
| Installation method | Back glue or screw |
| Electrostatic protection | 2KV |
| Personalization Options | Custom color printed barcode text or personalized coding |
| Product Application Scenarios | Product tracking, product anti-counterfeiting, warehousing, production control, vehicles, pallet management, shelf management, warehouse logistics management, asset management and equipment inspection, production process management, tracking management, chemical logistics supply management and other rfid asset management. |
