EPC C1G2 BATTERYLESS SWITCH MONITOR
X5-R is an EPC Class-1 Generation-2 (C1G2) RFID tag based on Farsens’ batteryless sensor technology.Built in a compact PCB format, the tag includes a 5 channel switch monitor. These RFID sensor tags are compatible with
commercial UHF RFID readers (EPC C1G2). With a 2W ERP setup the battery-less resistance meter can
communicate to over 5 meters - 16 feet. The X5-R can be customized with different antenna design and sizes, depending on the specific application. It can be encapsulated in an IP67 or IP68 casing for usage in harsh environments.
Size: 137.20 X 19.20 X 10 mm
Standard EPC C1G2 (ISO18000-6C)
160-bit EPC Bank, 96-bit TID Bank, 1008-bit User
5 channel switch monitoring
Technical Parameters
RFID
| Model No. | EVAL01-X5-R-V03 |
|---|---|
| Standard | EPC C1G2 (ISO18000-6C) |
| Memory | 160-bit EPC Bank, 96-bit TID Bank, 1008-bit User |
| Operation range full passeive | 5 m |
| Operation range BAP | 15 m |
| Operation range EBAP | 20 m |
Operation Conditions
| Operating temperature range | -40~ 85 ℃ |
|---|---|
| Resistance for OPEN detection | 10 MΩ |
| Resistance for SHORT detection | 10 Ω |
