L6535 Printable UHF RFID Tag
L6535 The lable conforms to EPC C1G2 (ISO18000-6C) standard, working frequency 860~960MHz, with unique ID code, can store data, mainly used in clothing, logistics, asset management, etc.
coated paper
EPC Global Class1 Gen2 ISO18000-6C
US Standard 7.5m (2W Handset)
The number of erasable 100000 times
Technical Parameters
physical parameters
| Dimensions | 65 x35 mm |
|---|---|
| Materials | Surface Material Coated Paper Base material Glassin base paper |
| Installation method | Adhesive paste |
| Packing specification | 2000 tablets/roll (customizable) |
| Working temperature | -20~85 ℃ |
| Storage temperature | 20 ℃ ~ 35 ℃ |
| Storage humidity | 20 to 90% relative humidity |
| Storage life | More than 2 years (20°C ~ 30°C, 40 ~ 60% relative humidity) |
Electrical Performance
| Standard | EPC Class1 Gen2, ISO18000-6C |
|---|---|
| Frequency | (US Standard) 902-928MHz,(European Standard) 865-868MHz,(GB) 920-925MHz |
| Chip | NXP U9 |
| EPC memory | EPC code 128 bits; TID code 96 bits; User Storage: None |
| Read Distance | 9.5 m (tested with 2W handset) Reading distance is related to actual use, environment and label |
| Number of reads and writes | 100,000 times |
| Data saving | 10 years |
