U6 watch type UHF reader
U6 "Bee" is a new generation of bracelet-type feather-level micro reader introduced by Speedingiot. It can be connected to ios, android and other intelligent system platforms through Bluetooth interface, and can also be connected to computers through Type- c. Wristband design, better improve comfort. Change the original electronic tag reading and writing carrying mode, realize the miniaturization of RFID reading and writing, realize the real zero sense carrying work like a watch, and promote the real lightweight and popularization of RFID application system engineering.
Size 55x67x19mm
Weight 70g
Standard EPC C1 GEN2 / ISO18000-6C
System supports Android/iOS/applets
Support Bluetooth data communication
Interface Type-C Interface
RFID reading distance 0.1-1 meters; power maximum 26dBm
Protection IP67 portable bracelet flexible use
Technical Parameters
Basic parameters
| Overall size | 55x67x19mm |
|---|---|
| Weight of whole machine | 70g |
| Shell | ABS PC |
| Color | HOST BLACK LAKE BLUE |
| Buzzer | Software configurable with buzzer |
| Communication Interface | Type-C |
| Indicator light | Power indicator, Bluetooth indicator, work indicator |
| Bluetooth module | Bluetooth Low Energy 5.1 |
| Key | Scan key, power key |
Data acquisition
| Operating frequency | China 920-925 MHz; US 902-928 MHz; Europe 865-868 MHz |
|---|---|
| Protocol Standards | EPC C1 GEN2 / ISO18000-6C |
| Antenna Type | Grid Polarized Ceramic Directional Antenna |
| Power output | 0.5W(15 ~ 26dBm adjustable, step interval ± 1dBm) |
| Write card function | Support |
| card reading distance | 0.1-1 m, (the test condition is related to the tag type, transmission power and application environment, it is recommended to wear the test better) |
Related Functions
| System Support | Android, IOS, Windows, applets |
|---|---|
| Communication mode | Bluetooth transmission |
| Battery capacity | 1250 mAh rechargeable lithium battery |
| Standby time | 120 hours |
| Charging time | <3 hours |
| Working time | 8 hours/equalization mode |
| Charging mode | Type-C interface, charging output: 5V 0.5A ~ 3A |
| Protection level | IP67 |
Development Environment
| Operating System | Android, IOS or WeChat applet |
|---|---|
| SDK | Provide relevant SDK development package |
Use of the environment
| Working temperature | -25 ℃ to 50 ℃ |
|---|---|
| Storage temperature | -25 ℃ to 50 ℃ |
| Ambient humidity | 5% to 95% (non-condensing) |
Annex
| Standard accessories | Power adapter, wristband, warranty card, etc. |
|---|---|
| Custom Software | Custom stand-alone application software |
