KC3813 small anti-metal electronic tag

Fast wireless KC3813 is a long-distance electronic tag designed for metal objects, based on the development of R6P chip UHF RFID special tags. The size is 38 x 13 x 7.0mm, which meets the EPC Class 1 Gen 2 standard. When it is fixed on the surface of a metal asset, the reading distance can reach more than 6 meters. Miniaturization, protection level up to IP68, injection molding integrated packaging and other advantages enable it to meet industrial requirements, whether it is coating, spraying, quenching or injection molding and other industrial processes, even if the environment is harsh, KC3813 can also cope with freely, is the ideal choice for metal items/asset tracking management.
  • ※ physical parameters

    Size 38 x 13 x 7 mm
    Material Ceramic

  • ※ chip specifications

    Chip Impinj R6-P
    EPC 128 bits TID 96 bits User 32 bits

  • ※ RFID performance

    Standard EPC C1G2 (ISO18000-6C)
    Reading distance (4W ERP)6.0 m, metal surface

  • ※ data acquisition

    Data storage> 10 years
    The number of erasable 100000 times
    Installation method Industrial grade adhesive or epoxy adhesive, rivets

  • Technical Parameters

    RFID performance parameters

    Materialceramic high quality plastic
    Dimensions38 x 13 x 7mm; rivet holes 3.4mm x 2
    Weight7.4g
    ColorBlack
    StandardEPC C1G2 (ISO18000-6C)
    Frequency(US Standard) 902-928MHz,(European Standard) 865-868MHz
    ChipImpinj R6-P
    EPC memory128 bits
    TID96 bits
    USER32 bits
    Waterproof gradeIP68
    Read Distance (2W ERP)6 m, metal surface
    Data storage50 years
    Number of erasable100,000 times

    Other parameters

    Working temperature-30~85 ℃
    Storage temperature-30~300 ℃
    Operating humidity10%-95%
    Installation methodIndustrial grade viscose or epoxy glue, rivets
    Customized contentLogo, bar code/two-dimensional code, serial number, code writing, antenna design, etc.
    Product Application ScenariosAsset management in high temperature environment, heavy asset management, smelting, extraction, spraying process, etc.
