General Intelligent Gateway

The general intelligent gateway developed by Xunjie Wireless adopts edge computing architecture, supports localized data processing, storage and analysis, and can realize intelligent management of distribution network, with reliability, economy, versatility, intelligence and other characteristics. The core control module of the general intelligent gateway product adopts a Cortex-A53 architecture dual-core processor with a main frequency of 1.35GHz, integrated 1GB DDR3 and 8GB Flash memory, and adopts a real-time embedded Linux operating system to build a high-performance, large-capacity, high-reliability intelligent gateway platform.
  • ※ basic performance

    CPU dual-core, 1.35G; Memory 1GB 8GB

  • ※ communication function

    RS485 communication 4G communication, Bluetooth communication, 2.4G communication, LORA communication, Wi-Fi communication

  • Technical Parameters

    Technical parameters

    AppearanceSize 150mm * 148mm * 32mm
    Material Cast Aluminum
    CPU ProcessorDual Core, 1.35G
    Running memoryDDR3 1GB
    Non-volatile storage8GB
    switching power supplyInput voltage: AC (AC) 100-256V, frequency: 50Hz Output voltage: DC (DC) 12V
    Other

    Performance advantages

    InterfaceInterface LAN1, WAN1, USB interface 1, Console port 1 type-c interface
    CommunicationRS485 communication 4G communication, Bluetooth communication, 2.4G communication, LORA communication, Wi-Fi communication
    safe and reliable controlHardware DOG External Standalone Hardware Watchdog
    CPU on board temperature detection External independent hardware temperature detection
    super capacitorPower-off delay 15s
    RTCExternal independent RTC,
    Power consumption<6W

    Use of the environment

    Operating temperature:-25 ℃ ~ 80 ℃
    Relative humidity:≤99.9%RH
