UHF RF FIELD MONITOR
PHOTON-R is a UHF RF field monitor based on Farsens’ batteryless sensor technology. Built in a compact PCB format, the tag includes a LED indicator that switches on in presence of RF field. These RFID sensor tags are compatible with commercial UHF RFID readers (EPC C1G2). With a 2W ERP setup the battery-less rf field monitor tag can operate to over 5 meters - 16 feet. The PHOTON-R can be customized with different antenna design and sizes, depending on the specific application. It can be encapsulated in an IP67 or IP68 casing for usage in harsh environments.
Size: 137.20 X 13.45 X 10 mm
Standard EPC C1G2 (ISO18000-6C)
160-bit EPC Bank, 96-bit TID Bank, 1008-bit User
Sparkling LED in presence of RF field
Super wide viewing angle at 120℃
Technical Parameters
RFID
| Model No. | EVAL01-PHOTON-R-V02 |
|---|---|
| Standard | EPC C1G2 (ISO18000-6C) |
| Memory | 160-bit EPC Bank, 96-bit TID Bank, 1008-bit User |
| Operation range full passeive | 5 m |
Operation Conditions
| Operating temperature range | -40~ 85 ℃ |
|---|---|
| LED color | Green |
| Dominant Wavelength | 525 nm |
| Viewing Angle | 120 degree |
