BATTERYLESS SENSOR DEVELOPMENT PLATFORM
MEDUSA-RM is an EPC Class-1 Generation-2 (C1G2) RFID tag based on Farsens'batteryless sensor technology. Built in a compact PCB format, the tag includes a microcontroller. This tag is intended for developers willing to build proprietary batteryless sensor tags. These RFID sensor tags are compatible with commercial UHF RFID readers (EPC C1G2). With a 2W ERP setup the battery-less development platform can communicate to over 5 meters - 16 feet. The actual communication distance can be reduced if additional power consumption is added to the tag.
Size: 137.20 X 31.55 X 10 mm
Standard EPC C1G2 (ISO18000-6C)
160-bit EPC Bank, 96-bit TID Bank, 1008-bit User
Example FW and SW for ADC reading
Technical Parameters
RFID
| Model No. | EVAL01-MEDUSA-RM-V01 |
|---|---|
| Standard | EPC C1G2 (ISO18000-6C) |
| Memory | 160-bit EPC Bank, 96-bit TID Bank, 1008-bit User |
| Operation range full passeive | 5 m |
| Operation range BAP | 15 m |
| Operation range EBAP | 20 m |
Operation Conditions
| Operating temperature range | -40~ 85 ℃ |
|---|
