AMBIENT TEMPERATURE AND BAROMETRIC PRESSURE SENSOR

FENIX-VORTEX-RM is an EPC Class-1 Generation-2 (C1G2) RFID tag based on Farsens'batteryless sensor technology. Built in a compact PCB format,the tag includes an ambient temperature sensor and a barometric pressure sensor. These RFID sensor tags are compatible with commercial UHF RFID readers (EPC C1G2). With a 2W ERP setup the battery-less resistance meter can communicate to over 5 meters - 16 feet. The FENIX-VORTEX-RM can be customized with different antenna design and sizes, depending on the specific application. It can be encapsulated in an IP67 or IP68 casing for usage in harsh environments. It may also be possible to customize the specifications of the sensor upon request.
  • ※ physical parameters

    Size: 137.25 X 16.05 X 10 mm

  • ※ RFID performance

    Standard EPC C1G2 (ISO18000-6C)

  • ※ Memory

    160-bit EPC Bank, 96-bit TID Bank, 1008-bit User

  • ※ Characters

    Ambient Temperature sensor
    Barometric Pressure sensor

  • 传感器应用横幅图

    Technical Parameters

    RFID

    Model No.EVAL01-FENIX-VORTEX-RM-V03
    StandardEPC C1G2 (ISO18000-6C)
    Memory160-bit EPC Bank, 96-bit TID Bank, 1008-bit User
    Operation range full passeive 5 m
    Operation range BAP15 m
    Operation range EBAP20 m

    Operation Conditions

    Operating temperature range-40~ 85 ℃
    Temperature range-30~ 85 ℃
    Temperature accuracy ±2(0℃to 65 ℃)
    Temperature resolution1/480
    Pressure range260-1260 hPa
    Pressure accuracy0.2 hPa
    Pressure resolution1/4096 hPa
    Pressure noise0.03 hPa
