C1207 Hospital Asset Tracking RFID Tag

The UHF tag C1207 has a hard ceramic exterior shield to protect them from exposure to extreme conditions. It can be mounted onto a variety of asset surfaces by either attaching it or embedding it. C1207 is IP68-rated and has heat resistance, water resistance and chemical resistance. The size is 12x7mm, the thickness is 3mm, and the weight is 1.6g. When it is installed on the metal asset surface, the reading range can reach 2.3 meters, So C1207 can be used as an UHF parking tag, it also can be used for rfid hospital asset tracking and more.
  • ※ Physical parameters

    Size 12 x 7.0 x 3.0 mm
    Material Ceramic

  • ※ Chip specifications

    Chip Alien Higgs-3
    EPC 96 bits TID 64 bits User 512 bits

  • ※ RFID performance

    Standard EPC C1G2 (ISO18000-6C)
    Reading distance (4W ERP)2.3 m, metal surface

  • ※ Data acquisition

    Data storage> 10 years
    The number of erasable 100000 times

  • Technical Parameters

    RFID performance parameters

    MaterialCeramics
    Dimensions12 x 7.0 x 3.0mm
    Weight1.6g
    ColorBlack
    StandardEPC C1G2 (ISO18000-6C)
    Frequency(US Standard) 902-928MHz,
    (European Standard) 865-868MHz,
    ChipAlien Higgs-3
    EPC memory96 bits
    TID64 bits
    USER512 bits
    Waterproof gradeIP68
    Read Distance (Fixed Reader)2.3 m, metal surface
    Read Distance(Handheld Reader)1.3 m, metal surface
    Data storage50 years
    Number of erasable100,000 times

    Other parameters

    Working temperature-40~+150 ℃
    Storage temperature-40~+85 ℃
    Operating humidity10%-95%
    Installation methodAdhesive
    Customized contentLogo, bar code/two-dimensional code, serial number, code writing, antenna design, etc.
    ApplicationInspection of electrical equipment, inspection of towers and poles, inspection of elevators, management of pressure vessels, cylinders and cylinders, management of automobile parts, management of medical devices, management of guns, etc.
