U8 wristband UHF reader

U8 "bumblebee" is a new generation of wearable RFID reader introduced by Speedingiot. based on IMPINJ's new generation of e-series chip design, it has high sensitivity, wide reading range, low power consumption and strong performance. it fully supports compliance with EPC Global C1 Gen2/ISO 18000-6C standard and is connected with ios, android and other system platforms through bluetooth interface for multi-tag reading. Wearable design changes the original way of reading and writing electronic tags, realizes miniaturization of RFID reading and writing, and truly realizes zero-sense carrying work. It can be used with shoulder straps, straps and mobile phones, thus promoting the real lightweight and popularization of RFID application system engineering. It can be widely used in logistics, access control, clothing, retail, warehousing, anti-counterfeiting and intelligent manufacturing and other radio frequency identification systems.
  • ※ Physical parameters

    Size 174 × 84 × 18mm
    Weight 320g

  • ※ Basic performance

    Standard EPC C1 GEN2 / ISO18000-6C
    Chip Impinj E series chip self-developed UHF module

  • ※ Wireless communication

    Interface 5.1 Bluetooth data communication;
    Interface Type-C Interface
    System Android/iOS/applet development

  • ※ Data acquisition

    RFID read distance 0.1-20 meters; maximum power 33dBm
    Protection IP67 portable wristband for more flexible use

  • Technical Parameters

    Basic parameters

    Overall size174 × 84 × 18mm
    Weight of whole machine320g
    ShellTPU ABS PC
    Colorhost black
    BuzzerSoftware configurable with buzzer
    Communication InterfaceType-C data interface
    Indicator lightPower indicator, Bluetooth indicator, work indicator
    Bluetooth moduleBluetooth Low Energy 5.1
    KeyScan key (left and right), power key

    RFID UHF

    Operating frequencyChina 920-925 MHz;
    USA 902-928 MHz;
    Europe 865-868 MHz
    Protocol StandardsEPC C1 GEN2 / ISO18000-6C
    Antenna TypeGrid Polarized Ceramic Directional Antenna
    Power output2W(5 ~ 30dBm adjustable, step interval ± 1dBm)
    communication rate115200bps
    Receiving sensitivity-73dBm
    Write card functionSupport
    Group Read Rate350 tags/sec
    card reading distance1-20 m (test case is related to tag type, transmit power and application environment)

    Performance parameters

    System SupportAndroid, IOS, applets
    Communication modeBluetooth transmission
    Battery capacity:5600 mAh rechargeable lithium battery
    Standby time360 hours
    Charging time<6 hours
    Working time:14 hours/equalization mode
    Charging mode:Type-C interface, charging output: 5V 0.5A ~ 3A
    Protection levelIP67

    Development Environment

    Operating SystemAndroid, IOS or WeChat applet
    SDKProvide relevant SDK development package

    Use of the environment

    Working temperature-25 ℃ to 50 ℃
    Storage temperature-20 ℃ to 70 ℃
    Ambient humidity5% to 95% (non-condensing)

    Annex

    Standard accessoriesPower adapter, wristband, warranty card, etc.
    OptionalOptional magnetic wrist strap bracket
