N6040 high frequency anti-metal drip card
Fast wireless N6040 is made of high-quality PVC material and high-frequency chip encapsulated by dropping glue. Through high-temperature hot pressing process, the product is firmly bonded and the surface is smooth. The label has good reading performance, the working frequency is 13.56MHz, the surface of the label card can be customized color pattern, bar code data, card number data, in addition, according to different application scenarios, can be pasted with adhesive, punching and other processes.
Size 60 x 40 x 3.0mm
Material PVC drop glue anti-metal layer 3M 9448A glue
Chip NTAG 213
Frequency 13.56 MHz to 14.2 MHz
Standard ISO 14443 A
Reading distance 2~10cm
Data storage> 10 years
The number of erasable 100000 times
Installation method Industrial grade viscose/high quality epoxy glue
Technical Parameters
RFID performance parameters
| Material | PVC drop glue anti-metal layer 3M 9448A glue |
|---|---|
| Dimensions | 60 x 40 x 3.0mm |
| Weight | 8.5g |
| Color | Reference physical object |
| Standard | ISO 14443 A |
| Frequency | 13.56 MHz~14.2 MHz |
| Chip | NTAG 213 |
| Application Media | Metal |
| Read Distance | 2~10cm (related to reader power and application environment) |
| Data storage | 50 years |
| Number of erasable | 100,000 times |
Other parameters
| Working temperature | -20°C to 75°C |
|---|---|
| Storage temperature | -30°C to 65°C |
| Operating humidity | 10%-95% |
| Installation method | Industrial grade viscose/high quality epoxy adhesive |
| Customized content | Logo, bar code/two-dimensional code, serial number, code writing, antenna design, etc. |
| Product Application Scenarios | Animal traceability and spare parts are used to realize product identification, tracking, traceability inquiry or supervision, including logistics supply chain, digital storage, traceability supervision, and relevant confidential documents, letters, cheque invoices, certificates, examination paper cases, such as student ID cards, prison prisoner files, bank drafts, document bag seals, box seals, product QC/warranty seals, etc. |
