BATTERYLESS SOIL MOISTURE SENSOR

HYDRO-RM-H402 is an EPC Class-1 Generation-2 (C1G2) RFID tag based on Farsens'batteryless sensor technology. Built in a compact PCB format, the tag includes soil moisture sensor. These RFID sensor tags are compatible with commercial UHF RFID readers (EPC C1G2). With a 2W ERP setup the battery-less resistance meter can communicate to over 5 meters - 16 feet. The HYDRO-RM-H402 can be customized with different antenna design and sizes, depending on the specific application. It can be encapsulated in an IP67 or IP68 casing for usage in harsh environments. It may also be possible to customize the specifications of the sensor upon request.
  • ※ physical parameters

    Size: 137.25 X 17.05 X 10 mm

  • ※ RFID performance

    Standard EPC C1G2 (ISO18000-6C)

  • ※ Memory

    160-bit EPC Bank, 96-bit TID Bank, 1008-bit User

  • ※ Characters

    Resistive soil moisture sensor

  • 传感器应用横幅图

    Technical Parameters

    RFID

    Model No.EVAL01-HYDRO-RM-H402-V01
    StandardEPC C1G2 (ISO18000-6C)
    Memory160-bit EPC Bank, 96-bit TID Bank, 1008-bit User
    Operation range full passeive 5 m
    Operation range BAP15 m
    Operation range EBAP20 m

    Operation Conditions

    Operating temperature range-40~ 85 ℃
    Resistance wet10 Ω
    Resistance dry10 MΩ
