K8724 industrial grade anti-metal RFID tag
K8724 is a high-performance UHF RFID anti-metal tag. This product is widely used in indoor asset management, inspection management, and tool management. It is small in size, easy to install, and has stable and reliable product performance.
Size 87 x 24 x 11.0mm
Material PC
Chip Impinj R6-P
EPC 128 bits TID 96 bits User 32 bits
Standard EPC C1G2 (ISO18000-6C)
Reading distance (2W ERP)6.0m, metal surface
Reading distance (4W ERP)9.8m, metal surface
Data storage> 10 years
The number of erasable 100000 times
Installation method screw, adhesive
Technical Parameters
RFID performance parameters
| Material | PC |
|---|---|
| Dimensions | 87 x 24 x 11.0mm, (Hole: Diameter 5mm x 2) |
| Weight | 19g |
| Color | Black (optional red, blue, green, white) |
| Standard | EPC C1G2 (ISO18000-6C) |
| Frequency | 860-960MHz |
| Chip | Impinj R6-P |
| EPC memory | 128 bits |
| TID | 96 bits |
| User Area Memory | 64 bits |
| Waterproof grade | IP68 |
| Read Distance (2W ERP) | 6.0 m, metal surface 2.8 m, non-metallic surface |
| Read Distance (4W ERP) | 9.8 m, metal surface 4.8 m, non-metallic surface |
| Data storage | 50 years |
| Number of erasable | 100,000 times |
Other parameters
| Working temperature | -30~70 ℃ |
|---|---|
| Storage temperature | -30~70 ℃ |
| Operating humidity | 10%-95% |
| Installation method | Screw, adhesive |
| Customized content | Logo, bar code/two-dimensional code, serial number, code writing, antenna design, etc. |
| Product Application Scenarios | Electric power equipment inspection, electric tower pole inspection, elevator inspection, pallet management, large pressure vessel, liquefier cylinder, factory equipment management, line inspection, metal bridge quality inspection, tunnel inspection, machine identification, vehicle license plate, metal container management, product tracking of various electric household equipment, etc. |
