C80HC medical handheld terminal

C80HC medical handheld terminal is specially designed for the medical industry. It integrates temperature measurement and pupil lamp in the innovative industry. The medical care work is more efficient. A variety of scanning heads are freely and flexibly built, and bar codes such as wristbands and infusion bags of patients can be read accurately and quickly. IP67,1.5 m drop resistance, 360 super protection, strong and durable; Medical grade antibacterial shell can withstand disinfectant and alcohol wiping to prevent cross infection and make medical work safer. Help medical staff to easily cope with different subdivision scenes such as mobile nursing, emergency center, drug management, material traceability, SPD, etc. Innovative industry integrated temperature measurement, pupil lamp, medical work more efficient, a variety of scanning head free collocation, easy to deal with mobile care, emergency center, drug management, material traceability, SPD and other different sub-scenes.
  • ※ physical parameters

  • ※ basic performance

    System Android 11
    Eight-core 2.2GHz; Memory 4G 64G

  • ※ wireless communication

    WWAN 4G/3G/2G
    WiFi dual-band Bluetooth 5.0

  • ※ data acquisition

    Barcode recognition/NFC recognition/RFID recognition

  • Product characteristics

    Medical grade antibacterial material, protection IP67 grade

  • Extended functionality

    Optional infrared temperature measurement, ultra-long RFID

    • Technical Parameters

    Basic parameters

    Overall size162 x 76.8 x 13.9mm
    Weight of whole machine252 g (with battery)
    Display5.72 inch IPS screen, resolution: 1440*720
    Touch screenCapacitive touch, support wet hand/gloved input/5-point touch
    Battery capacityRemovable lithium ion battery, capacity: 4600mAh/6200mAh; 3.8V
    Backup battery (optional):150mAh;
    Standby time> 300 hours
    Working hours> 8 hours (depending on usage and network environment)
    Expansion Card Slot1 SIM card slot, 2 PSAM card slots,
    1 Micro SD
    Security PSAMSupport ISO7816 standard, support 2 PSAM cards
    Communication InterfaceType-C,OTG
    Network Connection4G/3G/2G, Wi-Fi, GPRS
    Notification MethodTone; Multi-color LED; Vibration
    Keyboard3 virtual keys: Back, Home, Menu
    AudioMicrophone, speaker, earpiece
    SensorLight sensor, Distance sensor, Gravity sensor,
    Geomagnetic sensor, Hall sensor (optional)
    KeyboardPower key; two scan keys; volume-, custom key
    AdapterInput: 100-240V,50/60HZ 300mA
    Standard charger output: 5V = 2A
    Fast charger output: 5V = 3A/9V = 2A/12V = 1.5A

    Performance parameters

    CPUEight-core 2.2GHz
    Operating SystemAndroid 11
    Memory4GB 64GB compatible with optional 6G 128G
    WWANAsian Band: GSM:Band 2/3/5/8 WCDMA:Band 1/2/5/8 TD-SCDMA:Band 34/39 CDMA:Band BC0 TDD-LTE:Band 34/38/39/40/41 FDD-LTE:Band 1/3/5/7/8/20
    US frequency: GSM:Band 2/3/5/8 WCDMA:Band 1/2/4/5 CDMA:Band BC0 TDD-LTE:Band 40/41 FDD-LTE:Band B1/2/4/5/7/28A/28B
    WIFI FrequencyFrequency band: 2.4G/5.8G dual band
    IEEE802.11 a/B/g/n/ac protocol (support fast roaming)
    Positioning SystemBeidou, Glonass, GPS, Galileo, QZSS
    BluetoothBluetooth 5.0

    Development Environment

    SDKSDK
    Development LanguageJava
    Development ToolsEclipse / Android Studio

    Data acquisition

    barcode scanningProfessional scanning head, support mainstream one-dimensional code/two-dimensional code, support screen scanning code
    CameraFront camera: 5 million pixels FF
    Rear camera: 13 million pixel AF
    Rear secondary camera (optional):2 million pixels FF
    Rear camera flash; support flashlight mode

    Medical Related

    Infrared temperature measurement: support (optional)Measurement location: human body or object surface
    Measurement method: non-contact infrared measurement
    Measuring distance: 0~6cm Temperature measurement time: ≤ 1S
    Measurement range: human body: 34 ℃ ~ 42 ℃ object: 0 ℃ ~ 100 ℃
    Measurement accuracy: human body: 35 ℃ ~ 42 ℃ indoor error range of 0.2 ℃,
    Outdoor error range ± 0.3 ℃
    Object: ± 1.0 ℃
    Operating environment: temperature 0~35 ℃; relative humidity ≤ 85% Rh
    Antibacterial materialMedical grade antibacterial shell, easy to clean, resistant to high frequency disinfectants,
    Medical alcohol wipe; resist bacterial infection, medical work more secure

    Internet of Things Function

    RFIDWorking frequency: China 920-925 MHz;
    US 902-928 MHz; Europe 865-868 MHz
    Protocol standard: EPC C1 GEN2 / ISO18000-6C
    Reading distance of 0.8 meters (actual use and environment and label related)
    NFCOperating frequency: 13.56 MHz
    Protocol standards: IMifareClassic(MF1)NDEF,NfcV(15693),Ultraligh(MF0),IsoDep (Quasi-CPU MF3),IsoDep(CPU)
    Reading distance 0-5cm (actual use and the environment and label)
    HFOperating frequency band: 13.56MHz; support protocol: ISO15693 MHz
    Reading distance: 3-5cm (depending on card type)

    Use of the environment

    Working temperature-20 ℃ to 55 ℃
    Storage temperature-40 ℃ to 70 ℃
    Ambient humidity5% to 95% (non-condensing)
    Drop specificationWithstands multiple falls from a height of 1.5 meters to the marble floor
    Rolling specificationsCan withstand 200 1.6 feet/0.5 meters rolling impact;
    Meet or exceed IEC rolling specification requirements
    Rolling specificationsRandom (10Hz to 30KHz); 60 minutes per axis, 3 axes
    Electrostatic protection/- 10kv air discharge; /-6kv contact discharge
    Protection levelHost IP67

    Other

    CertificationCCE/CCC/UN38.3/RoHS/IP67/1.5 m drop/CTA/SRRC
    Standard accessories5V/2A adapter/data cable/battery/quick guide/certificate/UHF tag
    Optional AccessoriesSeat charger/battery/hand strap/lanyard/handle/tempered film/protective cover

    Annex

    Standard accessories5V/2A adapter/data cable/battery/quick guide/certificate/UHF tag
    Optional AccessoriesSeat charger/seat charger adapter/battery/tempered film/hand strap/lanyard/handle/fast charge
