EPC C1G2 BATTERYLESS LOAD SENSOR

ZYGOS-RM is an EPC Class-1 Generation-2 (C1G2) RFID tag based on Farsens'batteryless sensor technology. Built in a compact PCB format, the tag includes a load cell sensor mounted on a scale. These RFID sensor tags are compatible with commercial UHF RFID readers (EPC C1G2). With a 2W ERP setup the battery-less light sensor can communicate to over 5 meters - 16 feet. The ZYGOS-RM can be customized with different antenna design and sizes, depending on the specific application. It can be encapsulated in an IP67 or IP68 casing for usage in harsh environments. It may also be possible to customize the specifications of the sensor upon request.
  • ※ physical parameters

    Tag Size: 137.20 X 20.45 X 10 mm
    Sacle Size: 95 X 95 X 45 mm

  • ※ Load Sensor

    Load range:5 kg
    Load accuracy: : ±50 g

  • ※ RFID performance

    Standard EPC C1G2 (ISO18000-6C)

  • ※ Memory

    160-bit EPC Bank, 96-bit TID Bank, 1008-bit User

  • 传感器应用横幅图

    Technical Parameters

    RFID

    Model No.DS-EVAL01-ZYGOS-RM-V04
    StandardEPC C1G2 (ISO18000-6C)
    Memory160-bit EPC Bank, 96-bit TID Bank, 1008-bit User
    Operation range full passeive 5 m
    Operation range BAP15 m
    Operation range EBAP20 m

    Operation Conditions

    Operating temperature range-40~ 85 ℃
    Load range0~5 kg
    Load accuracy±50 g
    Load resolution5 g
