K5015 Anti-metal RFID electronic tag
Swift Wireless K5015 is a small size ABS anti-metal electronic tag, based on R6P chip development of UHF RFID special tags. Size 15x 50x 7.5mm, EPC Class 1 Gen 2 standard, protection up to IP54. The surface of this label can be customized, such as Logo, a two-dimensional code, etc. It can be installed in various ways. When it is fixed on the surface of metal assets, the reading distance can reach more than 12 meters.
Size 50 x 15 x 7.5mm
Material engineering plastics, surface material high quality PET
Chip Impinj R6P
EPC 128 bits TID 96 bits User 32 bits
Standard EPC C1G2 (ISO18000-6C)
Reading distance (2W ERP)12 m, metal surface
Reading distance (2W ERP)5 m, metal surface
Data storage> 10 years
The number of erasable 100000 times
Installation method Industrial grade adhesive/cable tie
Technical Parameters
RFID performance parameters
| Material | Label Material Engineering Plastic, Surface Material high quality PET |
|---|---|
| Dimensions | 50 x 15 x 7.5mm |
| Weight | 4.0g |
| Color | Customization |
| Standard | EPC C1G2 (ISO18000-6C) |
| Frequency | (US Standard) 902-928MHz,(European Standard) 865-868MHz,(China) 920-925MHz |
| Chip | Impinj R6P |
| EPC memory | 128 bits |
| TID | 96 bits |
| USER | 32 bits |
| Waterproof grade | IP54 |
| Read Distance (2W ERP) | 12 m, metal surface 5.0 m, non-metallic surface |
| Data storage | 50 years |
| Number of erasable | 100,000 times |
Other parameters
| Working temperature | -30~85 ℃ |
|---|---|
| Storage temperature | -30~125 ℃ |
| Operating humidity | 10%-95% |
| Installation method | Industrial grade viscose/cable ties |
| Customized content | Logo, bar code/two-dimensional code, serial number, code writing, antenna design, etc. |
| Product Application Scenarios | Widely used in indoor asset management, small tool management |
