E02 Conventional UHF access control

E02 is a high-performance UHF channel gate. Based on the design of high-performance read-write engine, it fully supports electronic tags conforming to EPCglobal C1 Gen 2 ISO 18000-6C and ISO18000-6B standards. It has excellent multi-tag reading performance, supports intensive reading, large-capacity tag reading and writing, and received signal strength detection (RSSI). Reliable network adaptability, support for a variety of communication protocols, support for Web Service development, large-scale application deployment is simple. It can be widely used in logistics, access control, clothing, retail, warehousing, anti-counterfeiting and intelligent manufacturing and other radio frequency identification systems.
  • ※ physical parameters

    Size 1505*371mm * 57mm mm/weight 30.3Kg

  • ※ basic performance

    Chip Impinj/domestic; Support optional Windows and Android industrial computer

  • ※ communication interface

    Support RS-232, TCP/IP, WIFI,USB,4G (optional)

  • ※ Standard Protocol

    EPC C1 GEN2 / ISO18000-6C or GJB7377.1-2011

  • ※ RFID performance

    Power 0 ~ 33dBm adjustable; rate 900 label/sec

  • ※ Advantage Features

    Simple multi-port design, simple operation, flexible deployment

  • Technical Parameters

    physical parameters

    Dimensions1505mm * 371mm * 57mm
    WeightNet weight: 30.3kg Gross weight: 39.4kg
    MaterialsPanel engineering plastic, body material aluminum alloy
    AppearanceDefault color: beige silver gray
    LED light barDefault red and green two-color, red, green and blue three-color optional
    Infrared2 pairs
    Installation methodSlot-free, with stainless steel trunking

    Performance parameters

    Operating frequency865~868MHz/902~928MHz (can be adjusted according to different countries or regions)
    Output powerOutput power software adjustable, step interval ± 1db, maximum 33dbm
    Tag Cache20W labels @ 96bit EPC
    Working modeMaster-slave mode/stand-alone mode/trigger mode
    RSSI strength detectionSupport
    Overall power5W ~ 24W
    Group Read Rate900 tags/sec (test condition is related to tag type, transmit power and application environment)
    industrial computerIndustrial control machine optional, size 10.1 inches, Android/Windows optional
    Network ProtocolTCP/IP, DHCP, SSH, FTP, Telnet, UDP
    Equipment power supplyPower adapter: AC input 100~240V/50-60Hz DC -- output 12V/5A
    DC power supply: 12V ~ 24V/5A
    Communication ProtocolRS-232, TCP/IP, Modbus, HTTP/HTTPS, MQTT, RabbitMQ
    Hardware InterfaceRJ45
    Development LanguageC#, Java
    Development EnvironmentLinux, Android, Windows, PLC, Web
    Reader operating modeMaster-slave mode/stand-alone mode/trigger mode
    Equipment power supplyPower adapter: AC input 100~240V/50-60Hz DC -- output 12V/5A
    DC power supply: 12V ~ 24V/5A

    Environmental parameters

    Working temperature-10 ℃ -50 ℃
    Operating voltageAC220V ± 10%
