C0505 High Temperature Ceramic Anti-metal Label

Speedingiot C0505 is a miniature anti-metal electronic tag, based on the development of R6P chip UHF RFID ceramic tag. Size 5 x 5 x 3mm, EPC Class 1 Gen 2, designed for very small metal objects. When it is fixed on the surface of metal assets, the reading distance can reach more than 2 meters. Ambient temperature -40-280 ℃, small size, can be embedded in the mold, can be used in various types of application environment, such as armory tracking, marking important assets, tracking high-value metal precious products, etc.
  • ※ physical parameters

    Size 5 x 5 x 3 mm
    Material Ceramic

  • ※ chip specifications

    Chip Impinj R6-P
    EPC 128 bits TID 96 bits User 32 bits

  • ※ RFID performance

    Standard EPC C1G2 (ISO18000-6C)
    Reading distance (4W ERP)2.0 m, metal surface

  • ※ data acquisition

    Data storage> 10 years
    The number of erasable 100000 times
    Installation method Industrial grade viscose/high quality epoxy glue

  • Technical Parameters

    RFID performance parameters

    MaterialCeramics
    Dimensions5 x 5x 3.0mm
    Weight0.4g
    Colorsilver, customizable
    StandardEPC C1G2 (ISO18000-6C)
    Frequency(US Standard) 902-928MHz,(European Standard) 865-868MHz,(GB) 920-925MHz
    ChipImpinj R6-P
    EPC memory128 bits
    TID96 bits
    USER32 bits
    Waterproof gradeIP68
    Reading distance (4W fixed machine)2.0 m, metal surface
    Data storage50 years
    Number of erasable100,000 times

    Other parameters

    Working temperature-30~85 ℃
    Storage temperature-30~250 ℃
    Operating humidity10%-95%
    Installation methodIndustrial grade viscose/high quality epoxy adhesive
    Customized contentLogo, bar code/two-dimensional code, serial number, code writing, antenna design, etc.
    Product Application ScenariosWidely used in tool tracking and management, mold management, precious electronic equipment management, etc.
