UL10012 file led bright light label (green light)
Speedingiot LED acousto-optic tags basically add acousto-optic reminding function to traditional RFID/NFC tags, so as to quickly locate and find designated items (LED or Beeper sound reminding) in warehouse, freight station and other item management. They are widely used in warehouses, hospitals and libraries, and are mainly used in inventory item positioning, shelf positioning, clothing and hat search positioning, book search positioning and file search positioning as the main application fields.
Dimensions 100 mmx 12mm mm x 0.2mm
Material can be printed coated paper
Chip KX2005XB-L/T
TID 192bit EPC 240bit User 1312bit
Standard EPC C1G2 (ISO18000-6C)
Reading distance 1.5m
The number of erasable 100000 times
Installation method Paste
Technical Parameters
Performance parameters
| Physical dimensions (width x length x height): | 100 mmx 12 mm x 0.2mm |
|---|---|
| Material | Printable Coated Paper |
| Installation Method | Adhesive |
| Antenna Technology | Aluminum antenna |
| Technology | planar microstrip |
| release paper | Yellow back with printed Grasin release paper |
| Working frequency and protocol: | 920.5-924.5 MHz, ISO 18000-6C, EPC global C1Gen2 |
| Chip | KX2005XB-L/T |
| Chip Memory | TID/UID Upto 192bit EPC/Block Upto 240bit User 1312bit Reserve 64bit |
| Read Distance | 1.5 meters (related to reader power and application environment) |
| Data saving | 10 years |
| Light Color | Green Light |
Other parameters
| Personalization Options | Custom color printed barcode text or personalized coding |
|---|---|
| Electrostatic protection | 2KV |
| Installation method | Paste |
| Compatible Printer | Zebra ZT411RFID ZT231 Bosch TX Series Han Yin IT4R Ming Xing CA9800 |
| Mode of supply | The quantity of rolls supplied is 1000-3000 pieces per roll (see additional instructions for special requirements) |
| Product Application Scenarios | Cainiao courier station goods, Chinese herbal medicine picking, supermarket warehouse search, experimental sample search and other application fields |
| Working temperature | -20~65 ℃ |
| Storage temperature | -0 to 45 ℃ |
| Working humidity | 10% to 90% |
