P6020LM PCB Light Label
The P6020LM is a new indicator tag with LED indicator light for precise positioning. It not only has the function of an ordinary RFID tag, but also can flash when the tag is positioned, allowing users to identify items more intuitively, realizing LED highlights to quickly locate the location of goods, and helping to complete the picking operation quickly and in time. The LED indicator label can be widely used in warehouse management, library management, file management, logistics management, jewelry industry and power industry. It is a high-performance UHF RFID anti-metal tag.
Size 60 x 20 x 3.0mm
Material FR4 (PCB)
Chip XBL2005-KX
EPC 128 bits TID 96 bits User 1312 bits
Standard EPC C1G2 (ISO18000-6C)
Reading distance (4W ERP)7.0m, metal surface
The number of erasable 100000 times
Installation method Industrial grade viscose/high quality epoxy glue
Technical Parameters
Performance parameters
| RFID Protocol | EPC Class1 Gen2, ISO18000-6C |
|---|---|
| Dimensions | 60 x 20 x 3.0mm |
| Weight | 7.5g |
| Materials | PCB |
| Color | Black |
| RFID Protocol | EPC Class1 Gen2, ISO18000-6C |
| Frequency | (US Standard) 902-928MHz, (European Standard) 865-868MHz |
| Storage | EPC 128bits , USER1312 bits, TID 96bits |
| Number of writes | 100,000 times |
| Application surface | Non-metallic surface |
| Data saving | 10 years |
| Light Color | Green Light |
| Read Pitch (4 Watt Fixed Machine) | 7.0 m, (US) 902-928MHz 5.6 meters, (European standard) 865-868MHz |
| Read Pitch:(2 Watt Handset) | 4.0 meters, (US standard) 902-928MHz, Light distance up to 3.0 meters 3.0 meters, (European standard) 865-868MHz |
Other parameters
| Personalization Options | Custom color printed barcode text or personalized coding |
|---|---|
| Electrostatic protection | 2KV |
| Installation method | Paste |
| Compatible Printer | Zebra ZT411RFID ZT231 Bosch TX Series Han Yin IT4R Ming Xing CA9800 |
| Mode of supply | Quantity of supply package 100-1000 pieces (see additional instructions for special requirements) |
| Product Application Scenarios | Cainiao courier station goods, Chinese herbal medicine picking, supermarket warehouse search, experimental sample search and other application fields |
| Working temperature | -20~65 ℃ |
| Storage temperature | -0 to 45 ℃ |
| Working humidity | 10% to 90% |
