UL9530 LED Bright Lights Tags

The acousto-optic tag Speedingiot developed basically adds acousto-optic reminder function to the traditional RFID/NFC tag, so as to quickly locate and find the specified item (LED or Beeper sound reminder) in the management of goods such as warehouses and freight stations. It is widely used in warehouses, hospitals and libraries, and is mainly used in the main application fields of inventory item positioning, shelf positioning, clothing and hat search positioning, book search positioning and file search positioning.
  • ※ physical parameters

    Size 95 mm x 30mm mm x 0.2mm
    Material can be printed white PET material

  • ※ chip specifications

    Chip KX2005XB-L/T
    TID 192bit EPC 240bit User 1312bit

  • ※ RFID performance

    Standard EPC C1G2 (ISO18000-6C)
    Reading distance 2.0m

  • ※ other parameters

    The number of erasable 100000 times
    Installation method Paste

  • Technical Parameters

    Performance parameters

    Physical dimensions (width x length x height):95 mmx 30 mm x 0.2mm
    MaterialPrintable white PET material
    Installation MethodAdhesive
    Antenna TechnologyAluminum antenna
    Technologyplanar microstrip
    release paperWhite Grasin release paper
    Working frequency and protocol:860-960Mhz, ISO 18000-6C, EPC global C1Gen2
    ChipKX2005XB-L/T
    Chip MemoryTID/UID Upto 192bit EPC/Block Upto 240bit User 1312bit Reserve 64bit
    Read Distance2.0 meters (related to reader power and application environment)
    Data saving10 years
    Light ColorGreen Light

    Other parameters

    Personalization OptionsCustom color printed barcode text or personalized coding
    Electrostatic protection2KV
    Installation methodPaste
    Compatible PrinterZebra ZT411RFID ZT231 Bosch TX Series Han Yin IT4R Ming Xing CA9800
    Mode of supplyThe quantity of rolls supplied is 1000-3000 pieces per roll (see additional instructions for special requirements)
    Product Application ScenariosCainiao courier station goods, Chinese herbal medicine picking, supermarket warehouse search, experimental sample search and other application fields
    Working temperature-20~65 ℃
    Storage temperature-0 to 45 ℃
    Working humidity10% to 90%
