AL7320 UHF Anti Liquid label
L7320 sticker (anti-liquid) label conforms to EPC C1G2 (ISO18000-6C) standard, and its working frequency is 860~960MHz. Anti-liquid label is mainly used in the fields of wine (such as red wine, stele wine, white wine, etc.), cosmetics, drugs, pesticides, agricultural and sideline products, food, animal traceability and spare parts
Identification, tracking, and traceability inquiry or supervision of current products
Coated paper
EPC Global Class1 Gen2 ISO18000-6C
US Standard 5m (2W Handset)
The number of erasable 100000 times
Technical Parameters
Dimensions
| Materials | 73x20mm |
|---|---|
| Installation method | Surface Material Coated Paper Base material Glassin base paper |
| Packing specification | Adhesive paste |
| Working temperature | 2000 tablets/roll (customizable) |
| Working temperature | -40 ℃ ~ 85 ℃ |
| Storage temperature | 23±3℃ |
| Storage humidity | 50±15％relative humidity |
| Storage life | More than 2 years (23±3℃, 50±15％ relative humidity) |
Electrical Performance
| Standard | EPC Global Class1 Gen2 ISO18000-6C |
|---|---|
| Frequency | Full band 860-960MHz |
| Chip | Alien Higgs 10 |
| Memory | EPC code 96bits(128 bits) ； TID code 48 bits； User storage: 32bits(0 bit) |
| Read Distance | 5 m (tested with 2W handset) Reading distance is related to actual use, environment and label |
| Number of erasable | 100,000 times |
| Data saving | 10 years |
