P9525 UHF On-metal PCB Tag
Speedingiot P9525 research and development of a large size PCB anti-metal RFID tag, EPC Class 1 Gen 2 compliant, IP68 protection. The shell is enclosed by epoxy resin, which is strong and durable. Applicable to tools, molds, valuable electronic equipment and other asset management. Use high quality epoxy glue to fix on the surface of metal assets, reading distance of up to 9 meters. The label is light, easy to install, waterproof, high security, indoor and outdoor universal, is a high-quality choice for asset management.
Size 95 x 25 x 3.6mm
Material FR4(PCB)
Chip Alien Higgs-3, Impinj Monza 4QT
EPC 96 bits TID 64 bits User 512 bits
Standard EPC C1G2 (ISO18000-6C)
Reading distance (4W ERP) 9.5 m, metal surface (US); 9.6 m, metal surface (EU)
Data storage> 10 years
The number of erasable 100000 times
Technical Parameters
RFID performance parameters
| Material | FR4 surface material: industrial grade epoxy resin |
|---|---|
| Dimensions | 95 x 25 x 3.55mm |
| Weight | 18g |
| Color | Black (Optional: red, blue, green, white) |
| Standard | EPC C1G2 (ISO18000-6C) |
| Frequency | (US Standard) 902-928MHz,(European Standard) 865-868MHz |
| Chip | Alien Higgs-3, Impinj Monza 4QT |
| EPC memory | 96 bits(Up to 480bits) |
| TID | 64 bits |
| USER | 512 bits |
| Waterproof grade | IP68 |
| Reading distance (4W fixed machine) | 9.5m, metal surface (US) 9.6 m, metal surface (EU) |
| Reading distance (2W Handheld Reader) | 5.8m, metal surface (US) 4.3m, metal surface (EU) |
| Data storage | 50 years |
| Number of erasable | 100,000 times |
Other parameters
| Working temperature | -40°C ~+100°C |
|---|---|
| Storage temperature | -40°C ~+150°C |
| Operating humidity | 10%-95% |
| Installation method | Adhesive or Screws |
| Certifications | REACH, RoHS, CE |
| Customized content | Logo, bar code/two-dimensional code, serial number, code writing, antenna design, etc. |
| Product Application Scenarios | Inspection of electrical equipment, inspection of towers and poles, inspection of elevators, management of pressure vessels, cylinders and cylinders, management of automobile parts, management of medical devices, management of guns, etc. |
