LD1104 UHF (Windshield) Label
Swift Wireless L1104 Adhesive is an electronic label that can be printed using automobile windshield. It is compatible with EPC CIG2 and ISO 18000-6C standards. It adopts flexible design and can be installed on irregular planes or curved surfaces. It supports personalized customization services such as printing, code writing and printing. It is widely used in book management, fixed asset storage management and other fields.
Coated paper
EPC Global Class1 Gen2 ISO18000-6C
US Standard 9.0m (2W Handset)
The number of erasable 100000 times
Technical Parameters
physical parameters
| Dimensions | 110x40mm |
|---|---|
| Material | Surface material PET paper Base material Glassin base paper |
| Installation Method | Adhesive paste |
| Packing specification | 2000 tablets/roll (customizable) |
| Working temperature | -40~+85℃ |
| Storage temperature | 23±3 ℃ |
| Storage humidity | 50±15% relative humidity |
| Storage life | More than 3 years (20°C ~ 30°C, 40 ~ 60% relative humidity) |
Electrical Performance
| Standard | EPC Global Class1 Gen2 ISO18000-6C |
|---|---|
| Frequency | Full band 860-960MHz |
| Chip | Impinj M4QT |
| Memory | EPC code 96 bits; TID code 512 bits; User storage: 32 bits |
| Read Distance | 9m (tested with 2W handset) Reading distance is related to actual use, environment and label |
| Number of erasable | 100,000 times |
| Data saving | 10 years |
