P1307 Tool Class (PCB) Tag
Speedingiot P1307 is a small size PCB anti-metal tag that can be used for rfid warehouse management. The tag size is 13x 7, the thickness is 3.8mm, and the weight is 0.7g. The product has stable performance, strong anti-metal capability, IP68 protection grade, simple installation method, can be directly pasted or embedded in metal concave surface, and its reading distance can reach 2.5 meters.
Size 13 x 7 x 3.8mm
Material FR4
Chip Alien Higgs-3
EPC 96 bits TID 64 bits User 512 bits
Standard EPC C1G2 (ISO18000-6C)
Reading distance (4W ERP)2.5 m, metal surface
Data storage> 10 years
The number of erasable 100000 times
Technical Parameters
RFID performance parameters
| Material | FR4 |
|---|---|
| Dimensions | 13 x 7 x 3.8mm (hole: diameter 2.0mm x 2) |
| Weight | 0.7g |
| Color | Black, customizable |
| Standard | EPC C1G2 (ISO18000-6C) |
| Frequency | (US Standard) 902-928MHz,(European Standard) 865-868MHz,(GB) 920-925MHz |
| Chip | Alien Higgs-3 |
| EPC memory | 96 bits (expandable to 480bits) |
| TID | 64 bits |
| USER | 512 bits |
| Waterproof grade | IP68 |
| Reading distance (4W fixed machine) | 2.5 m, (US Standard) 902-928MHz, metal surface 2.4 m, (European standard) 865-868MHz, metal surface |
| Reading distance (2W for handset) | 1.5 m, (US Standard) 902-928MHz, metal surface 1.4 m, (European standard) 865-868MHz, metal surface |
| Data storage | 50 years |
| Number of erasable | 100,000 times |
Other parameters
| Working temperature | -40~150 ℃ |
|---|---|
| Storage temperature | -40~100 ℃ |
| Operating humidity | 10%-95% |
| Installation method | Adhesive or screw |
| Customized content | Logo, bar code/two-dimensional code, serial number, code writing, antenna design, etc. |
| Product Application Scenarios | Small tool management, precision measurement tool management, embedded management of items, etc. |
