P3613 UHF On-metal PCB Tag
P3613 is a medium-sized anti-metal RF electronic tag, UHF RFID special tag developed based on U8 chip. EPC Class 1 Gen 2 and RoHS compliant, IP68 protection. The shell is enclosed by high quality epoxy resin, which is strong and durable. Applicable to tools, molds, valuable electronic equipment and other asset management. Fix it on the surface of metal assets with high quality epoxy glue, with a reading distance of up to 9 meters. The label is light, easy to install, waterproof, high security, indoor and outdoor universal, is a high-quality choice for asset management.
Size 36 x 13x 3.5mm
Material FR4(PCB)
Chip Alien Higgs-3
EPC 96 bits (Up to 480bits) TID 64 bits User 512 bits
Standard EPC C1G2 (ISO18000-6C)
Reading distance (4W ERP)4.7 m, metal surface (US)；4.5 m, metal surface (EU)
Data storage> 10 years
The number of erasable 100000 times
Technical Parameters
RFID performance parameters
| Material | FR4 surface material: industrial grade epoxy resin |
|---|---|
| Dimensions | 36 x 13x 3.5mm |
| Weight | 3.5g |
| Color | Black (Optional: red, blue, green, white) |
| Standard | EPC C1G2 (ISO18000-6C) |
| Frequency | (US Standard) 902-928MHz,(European Standard) 865-868MHz,(GB) 920-925MHz |
| Chip | Alien Higgs-3 |
| EPC memory | 96 bits (Up to 480 bits) |
| TID | 64 bits |
| USER | 512 bits |
| Waterproof grade | IP68 |
| Reading distance (4W fixed machine) | 4.7 m, metal surface (US) 4.5 m, metal surface (EU) |
| Reading distance (2W Handheld Reader) | 2.7 m, metal surface (US) 2.5 m, metal surface (EU) |
| Data storage | 50 years |
| Number of erasable | 100,000 times |
Other parameters
| Working temperature | -40°C ~+100°C |
|---|---|
| Storage temperature | -40°C ~+150°C |
| Operating humidity | 10%-95% |
| Installation method | Adhesive or Screws |
| Certifications | REACH, RoHS, CE |
| Customized content | Logo, bar code/two-dimensional code, serial number, code writing, antenna design, etc. |
| Product Application Scenarios | Widely used in tool tracking and management, mold management, precious electronic equipment management, etc. |
