K5518 High Protecting Metal Tag
K5518 is a long-distance industrial level anti-metal electronic tag, based on R6P chip development of ultra-high frequency RFID special tags.according to EPC Class 1 Gen 2 standard, when it is fixed on the surface of metal assets, the reading distance can reach more than 5 meters. Widely used in forklift management, heavy asset management, container management, etc., protection grade IP68, waterproof, anti-ultraviolet acid and alkali resistance, can be used outdoors.
Size 55 x 18.5 x 5.1mm
Material ABS PC
Chip Impinj R6-P
EPC 128 bits TID 96 bits User 32 bits
Standard EPC C1G2 (ISO18000-6C)
Reading distance (2W ERP)5.0 m, metal surface
Data storage> 10 years
The number of erasable 100000 times
Technical Parameters
RFID performance parameters
| Material | ABS PC |
|---|---|
| Dimensions | 55 x 18.5 x 5.1mm |
| Weight | 4.2g |
| Color | Black, blue, red can be customized |
| Standard | EPC C1G2 (ISO18000-6C) |
| Frequency | (US Standard) 902-928MHz,(European Standard) 865-868MHz,(GB) 920-925MHz |
| Chip | Impinj R6-P |
| EPC memory | 128 bits |
| TID | 96 bits |
| USER | 32 bits |
| Waterproof grade | IP68 |
| Read Distance (2W ERP) | 5.0 m, metal surface |
| Data storage | 50 years |
| Number of erasable | 100,000 times |
Other parameters
| Working temperature | -30~85 ℃ |
|---|---|
| Storage temperature | -40~85 ℃ |
| Operating humidity | 10%-95% |
| Installation method | Screw, adhesive, cable tie |
| Customized content | Logo, bar code/two-dimensional code, serial number, code writing, antenna design, etc. |
| Product Application Scenarios | Metal asset equipment management, medical equipment management, automobile management, battery car management, power management, outdoor transportation containers, iron cans and other logistics management fields. |
