P2208 UHF On-metal PCB Tag
PM2208 is a small-size anti-metal radio frequency electronic tag, based on H3 chip developed UHF RFID special tag. EPC Class 1 Gen 2 compliant, IP68 protection. The shell is enclosed by epoxy resin, which is strong and durable. Applicable to tools, molds, valuable electronic equipment and other asset management. Fix it on the surface of metal assets with high quality epoxy glue, and read the maximum distance of 2.6 meters. The label is light, easy to install, waterproof, high security, indoor and outdoor universal, is a high-quality choice for asset management.
Size 22 x 8 x 3.8mm
Material FR4
Chip Alien Higgs-3
EPC 96 bits TID 64 bits User 512 bits
Standard EPC C1G2 (ISO18000-6C)
Reading distance (4W ERP)4.5m, metal surface
Data storage> 10 years
The number of erasable 100000 times
Technical Parameters
RFID performance parameters
| Material | FR4 surface material: industrial grade epoxy resin |
|---|---|
| Dimensions | 18 x 6 x 3 .8mm（Hole Diameter: 2mm） |
| Weight | 1.3g |
| Color | Black (Optional: red, blue, green, white) |
| Standard | EPC C1G2 (ISO18000-6C) |
| Frequency | (US Standard) 902-928MHz,(European Standard) 865-868MHz |
| Chip | Alien Higgs-3 |
| EPC memory | 96bits |
| TID | 512bits |
| USER | 64bits |
| Waterproof grade | IP68 |
| Reading distance (4W fixed machine) | 4.5 m, metal surface (US) 4.7 m, metal surface (EU) |
| Reading distance (2W Handheld Reader) | 2.6 m, metal surface (US) 3.0 m, metal surface (EU) |
| Data storage | 50 years |
| Number of erasable | 100,000 times |
Other parameters
| Working temperature | -40°C ~+100°C |
|---|---|
| Storage temperature | -40°C ~+150°C |
| Operating humidity | 10%-95% |
| Installation method | Industrial grade viscose/high quality epoxy adhesive |
| Certifications | REACH, RoHS, CE |
| Customized content | Logo, bar code/two-dimensional code, serial number, code writing, antenna design, etc. |
| Product Application Scenarios | Widely used in tool tracking and management, mold management, precious electronic equipment management, etc. |
