P0803 UHF On-metal PCB Tag
Speedingiot P0803 is a compact UHF anti-metal RFID tag, measuring 8×3×3mm (L×W×H). It features stable performance, small size, easy installation and high recognition sensitivity. Compliant with EPC Class 1 Gen 2 and ISO18000-6C standards, it has an IP68 protection rating and offers a reading distance of up to 0.95m when mounted on metal surfaces. Suitable for RFID tool management, this tag is also applicable to smart tool cabinets, small metal equipment management, surgical instrument tracking, metal fixed asset management, firearm management and other RFID-enabled scenarios.
Size 8 x 3 x 3 mm
Material FR4(PCB)
Chip Impinj R6-P
EPC 96 bits TID 64 bits User 512 bits
Standard EPC C1G2 (ISO18000-6C)
Reading Distance (4W ERP): 0.95m (US Standard, 902-928MHz) on metal surfaces; 0.9m (EU Standard, 865-868MHz) on metal surfaces.
Reading Distance (2W Handheld Reader): 0.5m (US Standard, 902-928MHz) on metal surfaces; 0.45m (EU Standard, 865-868MHz) on metal surfaces.
Data storage> 10 years
The number of erasable 100000 times
Technical Parameters
RFID performance parameters
| Material | FR4 (PCB) |
|---|---|
| Dimensions | 8 x 3 x 3 mm |
| Weight | 0.5g |
| Color | Black (Optional: Red, Blue, Green, White) |
| Standard | EPC C1G2 (ISO18000-6C) |
| Frequency | (US Standard) 902-928MHz,(European Standard) 865-868MHz |
| Chip | Alien Higgs-3 |
| EPC memory | 96 bits (expandable to 480 bits) |
| TID | 64 bits |
| USER | 512 bits |
| Waterproof grade | IP68 |
| Reading distance (4W fixed machine) | 0.95m (US Standard, 902-928MHz) on metal surfaces; 0.9m (EU Standard, 865-868MHz) on metal surfaces. |
| Reading Distance (2W Handheld Reader) | 0.5m (US Standard, 902-928MHz) on metal surfaces; 0.45m (EU Standard, 865-868MHz) on metal surfaces. |
| Data storage | 50 years |
| Number of erasable | 100,000 times |
Other parameters
| Working temperature | --40°C~ +150°C |
|---|---|
| Storage temperature | -40°C ~+100°C |
| Installation method | Industrial grade epoxy adhesive |
| Certifications | Reach, RoHS, CE |
| Customized content | Logo, bar code/two-dimensional code, serial number, code writing, antenna design, etc. |
| Product Application Scenarios | Small tool management, precision measurement tool management, embedded management of items, etc. |
