ET-U05 RFID Intelligent Toolkit
ET-U05 is an RFID intelligent toolkit that complies with the ISO18000-6C protocol. Based on RFID automatic identification technology, it can achieve functions such as off-site inventory and missed reminders of maintenance tools, avoiding safety accidents caused by maintenance tools being missed on site during on-site operations. Applied to on-site operation and maintenance scenarios such as high-speed rail and subway maintenance, aviation maintenance, and power station inspection.
Size 450*210*390mm
Standard EPC C1 GEN2 / ISO18000-6C
Bluetooth Low Energy 5.0
power-off 1-30dBm
Technical Parameters
Basic parameters
| Overall size | 450*210*390mm |
|---|---|
| Weight of whole machine | 3.5Kg |
| Shell | Electromagnetic shielding material+Oxford cloth |
| Color | Black |
| Buzzer | Software configurable with buzzer |
| Communication Interface | Type-C data interface |
| Display screen | LCD display |
| Bluetooth module | Bluetooth Low Energy 5.0 |
| Button | Inventory button |
RFID UHF
| Operating frequency | China 920-925 MHz; USA 902-928 MHz; Europe 865-868 MHz |
|---|---|
| Protocol Standards | EPC C1 GEN2 / ISO18000-6C |
| Antenna Type | Grid Polarized Ceramic Directional Antenna |
| Power output | 2W(5 ~ 30dBm adjustable, step interval ± 1dBm) |
| Group Read Rate | 200 tags/sec |
| Inventory time | ＜5s |
Performance parameters
| System Support | Android, IOS |
|---|---|
| Communication mode | Bluetooth transmission |
| Battery capacity: | 8000 mAh rechargeable lithium battery |
| Working time: | 72 hours/equalization mode |
| Charging mode: | Type-C interface, charging output: 5V 0.5A ~ 3A |
Development Environment
| Operating System | Android, IOS |
|---|---|
| SDK | Provide relevant SDK development package |
Use of the environment
| Working temperature | -25 ℃ to 50 ℃ |
|---|---|
| Storage temperature | -20 ℃ to 70 ℃ |
| Ambient humidity | 5% to 95% (non-condensing) |
Annex
| Standard accessories | Power adapter, warranty card, etc. |
|---|
