S801 Android Industrial Tablet
S801 is a high-performance and high-expansion Android industrial tablet, integrated RFID function and scanning engine, optional fingerprint, ID card data acquisition, battery 8000 mA, to meet a variety of scenarios under the application. Developed in Android 10 system, equipped with eight nuclear processor and with a dominant frequency of up to 2.0GHz, IP67 high protection level ensures the reliability of the equipment in various harsh environments. The equipment is widely used in industrial inspection, warehousing and logistics, infrastructure sites, manufacturing, chemical mining, and other industries to help achieve efficient management and operation of work.
Size 230 x 146 x 20mm
Screen 8-inch IPS HD screen, resolution 800*1280
CPU eight core 2.0GHz
Operating System Android 10
WWAN 4G/ WIFI Dual Band/BT4.2
Barcode recognition RFID UHF and NFC high frequency reading
Biometric ID, fingerprint, PSAM encryption
IP67 / 1.8m drop resistance
Technical Parameters
Basic parameters
| Overall size | 230 × 146 × 20mm |
|---|---|
| Weight of whole machine | 670g (standard weight) |
| Display | 8 inch IPS HD screen, resolution 800*1280 |
| Touch screen | Corning Gorilla Three Generation Industrial Multi-touch Capacitive Screen |
| Expansion slot | Support 2 PSAM cards (Expandable 4 PSAM cards) 1 MicroSd(TF) card slot |
| Communication Interface | 1 Type-c interface, 1 Type-A interface, 1 4.0 rod insertion charging port |
| Indicator light | Charging indicator |
| Keyboard | Side scan key, side function key |
| Camera | Front 5 million pixel, rear 13 million pixel camera with flash, auto focus function |
| Flashlight | Low power LED lighting, emergency use |
| GPS | Navigation built-in GPS global positioning system, error range ± 5m |
Performance parameters
| CPU | Eight-core 64-bit, frequency 2.0GHz |
|---|---|
| Memory capacity | RAM:2GB ROM:16GB (standard) RAM:4GB ROM:64GB (optional) |
| Extended Memory | Support 256GB Micro Sd card |
| Operating System | Android 10.0 4G:TD-LTE Band38/39/40/41 FDD-LTE Band 1,2,3,4,7,17,20 3G:WCDMA( 850/1900/2100MHz); |
| Data Communication | 2G:GSM/GPRS/Edge (850/900/1800/1900MHz) |
| WIFI | 2.4G/5G dual band, IEEE802.11a/B/g/n/ac |
| Bluetooth | Meets Bluetooth 4.2 |
Working environment
| Operating temperature | -20 ℃ ~ 50 ℃ |
|---|---|
| Storage temperature | -20 ℃ ~ 70 ℃ |
| Relative humidity | 5% ~ 95% non-condensing |
| Protection level | Host IP67 |
Battery performance
| Battery capacity | 8000mAh lithium polymer battery |
|---|---|
| Standby time | Turn off wireless communication and other functions can be standby for 720 hours |
| Charging time | Less than 6 hours |
| Working time | More than 14 hours (a full charge) |
two-dimensional bar code
| 2D Scan Engine | Honeywell-6703/Other |
|---|---|
| Support 2D barcode type | PDF417, MicroPDF417,Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode, Postal Codes,US PostNet,US Planet, UK Postal, Australian Postal,Japan Postal, Dutch Postal, etc. |
UHF
| Support Frequency | 915MHz, 865MHz (865-868MHz or 902-928MHz) |
|---|---|
| Support Agreement | For EPC C1 GEN2ISO18000-6C Agreement Optional 1.5 m distance (label and environment dependent) |
| Reading distance | Optional distance of more than 5 meters (label and environment related) |
high frequency
| Support Frequency | 13.56MHz |
|---|---|
| Support Agreement | For ISO15693, ISO14443 dual protocol |
| Reading distance | 0-7cm (label and environment related) |
| low frequency | 125K/134.2K animal ear tag |
| High frequency (CPU card) | Support CPU card read and write with PSAM use |
ID card identification (optional)
| Related Functions | Collection and identification of second-generation ID cards, identification |
|---|
Fingerprint Identification (optional)
| Module function | Fingerprint entry/comparison/deletion, image processing, etc. |
|---|---|
| Sensor | TCSI biometric fingerprint/FBI fingerprint authentication |
| Sensor Type | capacitive inductive |
| Image Size | 256*360pixel |
| Resolution | 500 DPI |
| Storage capacity | 1000 pieces. |
Annex
| Standard | Lithium battery, power adapter, DC charging cable, USB data cable |
|---|
